Denon AVR-1610 Service Manual

113
AVR-1910/1620/1610/790/590
C1910 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1911 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1912,1913 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1914,1915 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C1916,1917 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1918 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1919 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1920 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1921 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1922,1923 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1924 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C1925 00D9630129909 C,CERAMIC HIK X7R1200PF-K/50V D011122777160S
C1926-1928 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1929 00D9630293602 C,ELECT 1UF-M/50V(Pb Free) D040010087150S
C1930 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1931 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1932 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1933 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1934 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C1935,1936 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1939 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C1940,1941 nsp C,CERAMIC T.C COG12PF-J/50V D010120167160S
C1942 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C1943,1944 nsp C,CERAMIC 20PF-J/50V D010200167160S
C1946 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1947 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1948 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1950 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1952 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1953 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1954 nsp C,CERAMIC 220PF-J/50V D010221167160S
C1956-1958 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1959 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1960 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1961 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C1965 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C1966 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1967 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C1968 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C1969 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1970 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1971-1973 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C1974 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1975 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1976-1981 nsp C,CERAMIC COG68PF-J/50V D010680167160S
C1982-1985 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
BD1900,1901 00D9630223009 R,THICK 0-J,1/16W
C20000006M160S
BD1902 963115003230S COIL,BEAD CBW160808U121T D340160811210S
CN1010 nsp CN.WAFER 12P L101100031210S
CN1017 nsp CN.WAFER 6P L101100030610S
CN1018 nsp CN.WAFER 8P L101100030810S
CN1104 nsp CN.WAFER 18P L101100031810S
Ref. No. Part No. Part Name Remarks ETRO Q'ty New
f

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
