Denon AVR-1610 Service Manual

114
AVR-1910/1620/1610/790/590
JACK1600 00D9630294601 JACK,D3.5 EARPHONE G40100350000YS
JACK1601 00D9630217905 TER,RCA 2PIN 1910, 790 G601206A0200YS
JACK1601 963643003580S TER,RCA 1PIN 1610, 1620, 590 G600107C0020YS
JACK1900 963643003460S TER,RCA 4PIN G602405BE310YS
JACK1901 00D9600281000 TER,RCA 1PIN G600102D04K01S
JACK1903 963646001770S TER,RCA 9PIN G607902AD013YS
L1900 00D9630115609 COIL INDUCTOR 33UH D330330700520S
XTAL1900 00D9630217400 CRYSTAL 14.31818MHZ E80014R318080S
OPT1600 00D9630113009 MODULE JST1165-B 1910, 790 E100116500030S
OPT1601 00D9630237503 MODULE JSR1165-C E100116500040S
OPT1602 00D9630237503 MODULE JSR1165-C E100116500040S
Ref. No. Part No. Part Name Remarks ETRO Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
