Denon AVR-1610 Service Manual

115
AVR-1910/1620/1610/790/590
PCB EXT_IN ASS'Y (1910/790 model)
Ref. No. Part No. Part Name Remarks ETRO Q'ty New
SEMICONDUCTORS GROUP
IC1800 00D9630024004 IC NJM2068M E3
J121206800020S
IC1801 00D2623174900 IC SN74HAHCT08 E3 J040740800180S
IC1802 00D9600174104 IC CXA1511M-T4 1910 J030151100010S
Q1805 00D9630120704 TR KRA102S J520010200210S
Q1806 00D9630121402 TR 2SA KRA104S R1 1910 J520010400210S
Q1807-1810 00D9630044301 TR KTC2875B(MB) J5222875B0010S
D1801,1802 963209003510S D,ESD CDS3C05HDMI1 E3 K067030500010S
D1807 00D9630355401 D,SWITCHING KDS4148U 1910 K005041480030S
ZD1800 963202003490S D,ZENER 0.2W 6.2V UDZ 1910 K06606R24P400S
CAPACITORS GROUP
C1800 nsp C,CERAMIC COG33PF-J/50V E3
D010330167160S
C1801 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C1802,1803 nsp C,CERAMIC 0.1UF-K/50V E3 D011104577160S
C1804,1805 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C1809,1810 nsp C,CERAMIC 330PF-J/50V E3 D010331167160S
C1814,1815 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C1817 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C1818 nsp C,CERAMIC COG33PF-J/50V E3 D010330167160S
C1819 nsp C,CERAMIC 0.1UF-K/50V E3 D011104577160S
C1820 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1821,1822 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1823 00D9609010010 C,ELECT 4.7UF-M/50V D040100087070S
C1824 00D9609010010 C,ELECT 4.7UF-M/50V E3 D0404R7087250S
C1825 nsp C,CERAMIC 1000PF-K/50V E3 D011102777160S
C1826,1827 nsp C,CERAMIC 100PF-J/50V E3 D010101167160S
C1828 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1829 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1830 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1831 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1832,1833 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1834,1835 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1836,1837 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1838 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1839 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1840 nsp C,CERAMIC 330PF-J/50V D010331167160S
C1841 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1842 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C1843 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) 1910 D040010087150S
C1844 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C1845 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1846 nsp C,CERAMIC 0.01UF-K/50V 1910 D010103777160S
C1847 00D9609008653 C,FILM 0.012UF-J/100V 1910 D02012306C060S
C1848 nsp C,CERAMIC 100PF-J/50V 1910 D010101167160S
C1849 00D9639005862 C,ELECT 47UF-M/16V 1910 D040470083080S
C1850 00D9609008653 C,FILM 0.012UF-J/100V 1910 D02012306C060S
C1851 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) 1910 D040R10087080S
C1852 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1853 nsp C,CERAMIC 220PF-J/50V 1910 D010221167160S
C1854 nsp C,CERAMIC 100PF-J/50V D010101167160S

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
