Denon AVR-1610 Service Manual

116
AVR-1910/1620/1610/790/590
C1855 nsp C,CERAMIC 0.1UF-K/50V 1910 D011104577160S
C1856 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C1857 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1858 nsp C,CERAMIC 220PF-J/50V D010221167160S
C1859 nsp C,CERAMIC 220PF-J/50V 1910 D010221167160S
C1860 nsp C,CERAMIC 0.1UF-K/50V 1910 D011104577160S
C1861 nsp C,CERAMIC 1000PF-K/50V E3 D011102777160S
C1862 nsp C,CERAMIC 0.1UF-K/50V E3 D011104577160S
OTHERS PARTS GROUP
BD1800,1801 963115003230S COIL,BEAD CBW160808U121T E3
D340160811210S
CN1007 nsp CN.WAFER 6P L101100030610S
CN1009 nsp CN.WAFER 14P L101100031410S
CN1800 nsp CN.WAFER 15P L101100031510S
JACK1800 00D9630333601 MINI DIN CONNECTOR 8P YKF51-5397N E3 G403515397000S
JACK1801 00D9630388203 TER,RCA 4PIN G602405B5500YS
JACK1802 00D9630132103 TER,RCA 4PIN G602405B0400YS
JACK1805,1806
00D9630244703 JACK,D3.5 EARPHONE 1910 G40130802000YS
JACK1807 90M-YT004640R MODULE JSR1165-C G601207AE020YS
L1800 00D9630223009 R,THICK 0-J,1/16W C20000006M160S
Ref. No. Part No. Part Name Remarks ETRO Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
