Denon AVR-1610 Service Manual

120
AVR-1910/1620/1610/790/590
53A nsp PCB VIDEO ASSY 1910BKE3 7025HK0817017 *
53A nsp PCB VIDEO ASSY 1910BKE2
7025HK0817067 *
53A nsp PCB VIDEO ASSY 1910SPE2
7025HK0817057 *
53A nsp PCB VIDEO ASSY 1910SPE1C
7025HK0817027 *
53A nsp PCB VIDEO ASSY 790BKE3
7025HK0817077 *
53A nsp PCB VIDEO ASSY 790BKEA
7025HK0817047 *
53 - PCB VIDEO *
54 - PCB DIGITAL IN/OUT *
52 nsp PCB EXT_IN ASSY 1910BKE3
7025HK0817018 *
52 nsp PCB EXT_IN ASSY 1910BKE2
7025HK0817068 *
52 nsp PCB EXT_IN ASSY 1910SPE2
7025HK0817058 *
52 nsp PCB EXT_IN ASSY 1910SPE1C
7025HK0817028 *
52 nsp PCB EXT_IN ASSY 790BKE3
7025HK0817078 *
52 nsp PCB EXT_IN ASSY 790BKEA
7025HK0817048 *
1 963416003360D WINDOW DISPLAY 1910
5077212762000S 1*
1 963416004090D WINDOW DISPLAY 790
5077212762010S 1*
2 963412000570D KNOB FUNCTION(KD) BK
5080211761000SZ 1
2 963412003660D KNOB FUNCTION SP
5087211901000S 1
3 00D9630362109 BADGE DENON BK
5630210028300S 1
3 00D9630362202 BADGE DENON SP
5630210028400S 1
4 963402003350D PANEL FRONT A 1910BKE3
3067214351000S 1*
4 963402003970D PANEL FRONT A 1910BKE2
3067214351100S 1*
4 963402003980D PANEL FRONT A 1910SPE2
3067214351200S 1*
4 963402004040D PANEL FRONT A 1910SPE1C
3067214351210S 1*
4 963402004080D PANEL FRONT B 790BKE3
3067214371000S 1*
4 963402004120D PANEL FRONT B 790BKEA
3067214371100S 1*
5 00D9630137807 LENS STANDBY
3710210503000S 1
6 963411003390D BUTTON POWER BK
5097213821000S 1
6 00D9630230005 BUTTON POWER SP
5097212358300SZ 1
7 963411002820S BUTTON-ASSY STANDBY(KD) BK
5098212361000SZ 1*
7 00D9630221904 BUTTON STANDBY SP
5097212368030SZ 1
8 00D9630362305 BUTTON 2KEY BK
5097213351000S 1
8 00D9630362501 BUTTON 2KEY SP
5097213351110S 1
8 963411001390D BUTTON 2KEY 790
5097213591000S 1
12 963419001760D COVER RCA BK
4317214171000S 1
12 963409003650S COVER RCA SP
4317214171100S 1
15 963412000560D KNOB VOLUME(KD) BK
5080211751000SZ 1
15 963412002920S KNOB VOLUME SP
5087211891000S 1
16 963411003370D BUTTON 1KEY 1910BK
5097213791000S 1*
16 963412003670D BUTTON 1KEY 1910SP
5097213791100S 1*
16-1 963411003770D BUTTON BUTTON 1KEY 790
5097213801000S 1*
17 963411003380D BUTTON CURSOR 5KEY BK
5097213811000S 1*
17 963411003680D BUTTON CURSOR 5KEY SP
5097213811100S 1*
18 00D9630364700 BUTTON 3KEY 1910BK
5097213331000S 2
18 00D9630364906 BUTTON 3KEY 1910SP
5097213331110S 2
18-1 963411001400D BUTTON 3KEY A 790
5097213601000S 1
18-2 963411001410D BUTTON 3KEY B 790
5097213611000S 1
19 00D9630365002 BUTTON WIN 3KEY BK
5097213371000S 2
19 00D9630365301 BUTTON WIN 3KEY SP
5097213371110S 2
20 963411003400D BUTTON WIN 3KEY C BK
5097213831000S 1*
20 963411003690D BUTTON WIN 3KEY C SP
5097213831100S 1*
28 nsp HEAT SINK MAIN
2120211438000S 1*
31 963252004340S POSISTOR
F320121021240S 1
32 nsp BRACKET PCB
4010210186000S 5
40 00D9630214607 CUSHION FOOT
4050211295000S 4
41 963407003330D FOOT
4000210261000S 4
42 nsp CHASSIS MAIN
3200212816000S 1*
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
