Denon AVR-1610 Service Manual

121
AVR-1910/1620/1610/790/590
43 nsp SUPPORTER PCB 4070001601010S 3
44 nsp BRACKET SAFETY
4010213606000S 1
z 46 963101003590D POWER TRANS MAIN E3
8200960660530S 1*
z 46 963101004010D POWER TRANS MAIN E2, EA
8200960660540S 1*
z 46 963101004070D POWER TRANS MAIN E1C
8200960660550S 1*
70 963406004350D CHASSIS BACK 1910E3
3207211806000S 1*
70 963406004360D CHASSIS BACK 1910E2
3207212806200S 1*
70 963406004370D CHASSIS BACK 1910E1C
3207212806500S 1*
70 963406004430D CHASSIS BACK 790BKE3
3207212806100S 1*
70 963406004440D CHASSIS BACK 790BKEA
3207212806300S 1*
72 00D9600192403 STOPPER CORD AC
4380210002000S 1
z 73 00D9630292205 CORD ASSY E3
L068125100020S 1
z 73 90M-ZC000600R CORD ASSY E2
L068250160020S 1
z 73 00D9630349909 CORD ASSY E1C
L068250060010S 1
z 73 963611001490S CORD ASSY EA
L068250100070S 1
74 00D9630158404 AC INLET E2, EA
G430040560020S 1
75 963409002050D SHEET WINDOW
1210210682000S 1
76 00D9630361302 CABINET TOP BK
3000210936000S 1
76 963401000730D CABINET TOP SP
3000210936200S 1
77 nsp CUSHION SIDE 1
4050212525000S 3
80 nsp SPACER CARD
4300210062000S 1
81 nsp CLAMP WIRE(MTG)
4330000310000S 2
82 nsp GASKET HDMI
4400210449000S 1*
83 nsp CUSHION BD
4050211845000S 1
84 nsp GASKET EMC A
4400210189000S 1*
85 963409001780D COVER SAFETY BK
4310212122020S 1
85 963409001790D COVER SAFETY SP
4310212122010S 1
86 963454001800D COVER HOLDER BK
4310213701000S 6
86 963454001810D COVER HOLDER SP
4310213701100S 6
87 00D9630268802 SHEET CABINET
1210210235000S 3
89 nsp GASKET EMC A
4400210179000S 1*
★ 90
963606004030S CABLE,FLAT CARD SHIELD 1.25MM
N714352534810S 1*
★ 91
nsp CLAMP CABLE TIE DACT-100A
4330040343010S 7
SCREWS
A nsp SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH
B020030081B10S 66
B nsp SCREW +2S 3*8 BK WASHER PI12 BK
1500001456020S 5
B nsp SCREW +2S 3*8 NI WASHER PI12 SP
1500001456030S 5
C nsp SCREW +2S 3*15 B-TYPE ZNW/BH
B020030151B10S 2
D nsp SCREW +2S 3*10 B-TYPE(DOT) BK/BH 1910E3,E2
B020030103B11S 37
D nsp SCREW +2S 3*10 B-TYPE(DOT) BK/BH 1910E1C
B020030103B11S 35
D nsp SCREW +2S 3*10 B-TYPE(DOT) BK/BH 790BKE3
B020030103B11S 36
D nsp SCREW +2S 3*10 B-TYPE(DOT) BK/BH 790BKEA
B020030103B11S 33
Ensp
SCREW +2S 3*14 P( Φ 6)+S-WASHER ZNY/HH
B018230141H11S
21
F nsp SCREW +2S 3*17 B-TYPE ZNW/BH
B020030171B10S 3
G 00D9630048307 SCREW +2S 4*8 B-TYPE(DOT) BK/BH BK
1500040083B10S 6
G 00D9639004012 SCREW +2S 4*8 B-TYPE(DOT) NI/BH SP
1500040084B10S 6
H nsp SCREW +3S 4*10 P+S-WASHER ZNW/BH
B028940101B10S 4
I nsp SCREW +2S 3*8 ZnY WASHER PI12
1500001456010S 1
K nsp SCREW +2S 3*5 B-TYPE ZNW/BH
B020030051B10S 2
L nsp SCREW +2S 3*10 B-TYPE BK/FH E2, EA
B020030103F10S 2
P nsp SCREW +2S 3*8 PI9.5 B-TYPE ZNW
1500001206010S 2
Q nsp SCREW +3S 3*8 BK/BH
B020930083B10S 4
S nsp SCREW +M 3*10 BK/BH E3
B000030103B10S 1
T nsp SCREW +2S 3*8(ROUND) BK/BH
B020230083B10S 3*
★ U
nsp SCREW +2S 3*5 B-TYPE ZNW/BH
B020030051B10S 2
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
