Denon AVR-1610 Service Manual

122
AVR-1910/1620/1610/790/590
PARTS LIST OF EXPLODED VIEW (1610/1620/590 model)
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : (Black model SP : (Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
50 nsp PCB MAIN ASSY 1610BKE3 7025HK0816010 *
50 nsp PCB MAIN ASSY 1610BKE2
7025HK0816050 *
50 nsp PCB MAIN ASSY 1610SPE2
7025HK0816040 *
50 nsp PCB MAIN ASSY 1610SPE1C
7025HK0816060 *
50 nsp PCB MAIN ASSY 1620SPE1C
7025HK0816020 *
50 nsp PCB MAIN ASSY 590BKE3
7025HK0816080 *
50 nsp PCB MAIN ASSY 590BKEA
7025HK0816030 *
11A nsp PCB FRONT ASSY 1610BKE3
7025HK0816011 *
11A nsp PCB FRONT ASSY 1610BKE2
7025HK0816051 *
11A nsp PCB FRONT ASSY 1610SPE2
7025HK0816041 *
11A nsp PCB FRONT ASSY 1610SPE1C
7025HK0816061 *
11A nsp PCB FRONT ASSY 1620SPE1C
7025HK0816021 *
11A nsp PCB FRONT ASSY 590BKE3
7025HK0816081 *
11A nsp PCB FRONT ASSY 590BKEA
7025HK0816031 *
z 9 - P/S UNIT *
10 - FUNC UNIT *
11 - FRONT UNIT *
13 - ENCODER UNIT *
14 - H/P UNIT *
21 - V.AUX UNIT *
22 - MIC UNIT *
27 - CNT UNIT *
29 - CABLE GUIDE UNIT *
61 - ENCODER CNT UNIT *
78 - SW UNIT *
79 - SW CNT UNIT *
51 nsp PCB INPUT ASSY 1610BKE3
7025HK0816012 *
51 nsp PCB INPUT ASSY 1610BKE2
7025HK0816052 *
51 nsp PCB INPUT ASSY 1610SPE2
7025HK0816042 *
51 nsp PCB INPUT ASSY 1610SPE1C
7025HK0816062 *
51 nsp PCB INPUT ASSY 1620SPE1C
7025HK0816022 *
51 nsp PCB INPUT ASSY 590BKE3
7025HK0816082 *
51 nsp PCB INPUT ASSY 590BKEA
7025HK0816032 *
57A nsp PCB POWER ASSY 1610BKE3
7025HK0816013 *
57A nsp PCB POWER ASSY 1610BKE2
7025HK0816053 *
57A nsp PCB POWER ASSY 1610SPE2
7025HK0816043 *
57A nsp PCB POWER ASSY 1610SPE1C
7025HK0816063 *
57A nsp PCB POWER ASSY 1620SPE1C
7025HK0816023 *
57A nsp PCB POWER ASSY 590BKE3
7025HK0816083 *
57A nsp PCB POWER ASSY 590BKEA
7025HK0816033 *
26 - 16GUIDE_L UNIT *
56 - SUPPLY UNIT *
z 57 - POWER UNIT *
63 - 16SPK UNIT *
71 - CNT1 UNIT *
55 963189003570D PCB 16HDMI ASSY E3
7025HK0816015 *
55 963189004150D PCB 16HDMI ASSY E2, E1C, EA
7025HK0816045 *
33 nsp PCB 5CHAMP ASSY 1610BKE3
7025HK0816016 *
33 nsp PCB 5CHAMP ASSY 1610BKE2
7025HK0816056 *
33 nsp PCB 5CHAMP ASSY 1610SPE2
7025HK0816046 *

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
