Denon AVR-1610 Service Manual

123
AVR-1910/1620/1610/790/590
33 nsp PCB 5CHAMP ASSY 1610SPE1C 7025HK0816066 *
33 nsp PCB 5CHAMP ASSY 1620SPE1C
7025HK0816026 *
33 nsp PCB 5CHAMP ASSY 590BKE3
7025HK0816086 *
33 nsp PCB 5CHAMP ASSY 590BKEA
7025HK0816036 *
53A nsp PCB VIDEO ASSY 1610BKE3
7025HK0816017 *
53A nsp PCB VIDEO ASSY 1610BKE2
7025HK0816057 *
53A nsp PCB VIDEO ASSY 1610SPE2
7025HK0816047 *
53A nsp PCB VIDEO ASSY 1610SPE1C
7025HK0816067 *
53A nsp PCB VIDEO ASSY 1620SPE1C
7025HK0816027 *
53A nsp PCB VIDEO ASSY 590BKE3
7025HK0816087 *
53A nsp PCB VIDEO ASSY 590BKEA
7025HK0816037 *
53 - VIDEO UNIT *
54 - DIGITAL IN/OU TUNIT *
1 963416003550D WINDOW DISPLAY 1610, 1620
5077212762020S 1*
1 963416003750D WINDOW DISPLAY 590
5077212762050S 1*
2 963412000570D KNOB FUNCTION(KD) BK
5080211761000SZ 1
2 963412003660D KNOB FUNCTION SP
5087211901000S 1
3 00D9630362109 BADGE DENON BK
5630210028300S 1
3 00D9630362202 BADGE DENON SP
5630210028400S 1
4 963402003540D PANEL FRONT B 1610BKE3
3067214361000S 1*
4 963402003840D PANEL FRONT B 1610BKE2
3067214361100S 1*
4 963402003810D PANEL FRONT B 1610SPE2
3067214361200S 1*
4 963402003850D PANEL FRONT B 1610SPE1C
3067214361210S 1*
4 963402003640D PANEL FRONT B 1620SPE1C
3067214361220S 1*
4 963402003930D PANEL FRONT B 590BKE3
3067214371010S 1*
4 963402003740D PANEL FRONT B 590BKEA
3067214371110S 1*
5 00D9630137807 LENS STANDBY
3710210503000S 1
6 963411003390D BUTTON POWER BK
5097213821000S 1
6 00D9630230005 BUTTON POWER SP
5097212358300SZ 1
7 963411002820S BUTTON-ASSY STANDBY(KD) BK
5098212361000SZ 1*
7 00D9630221904 BUTTON STANDBY SP
5097212368030SZ 1
8 00D9630362305 BUTTON 2KEY BK
5097213351000S 1
8 00D9630362501 BUTTON 2KEY SP
5097213351110S 1
8 963411001390D BUTTON 2KEY 590
5097213591000S 1
12 963419001760D COVER RCA BK
4317214171000S 1
12 963409003650S COVER RCA SP
4317214171100S 1
15 963412000560D KNOB VOLUME(KD) BK
5080211751000SZ 1
15 963412002920S KNOB VOLUME SP
5087211891000S 1
16 963411003370D BUTTON 1KEY 1610BK
5097213791000S 1*
16 963412003670D BUTTON 1KEY 1610SP, 1620SP
5097213791100S 1*
16-1 963411003770D BUTTON BUTTON 1KEY 590
5097213801000S 1*
17 963411003380D BUTTON CURSOR 5KEY BK
5097213811000S 1*
17 963411003680D BUTTON CURSOR 5KEY SP
5097213811100S 1*
18 00D9630364700 BUTTON 3KEY 1610BK
5097213331000S 2
18 00D9630364906 BUTTON 3KEY 1610SP, 1620SP
5097213331110S 2
18-1 963411001400D BUTTON 3KEY A 590
5097213601000S 1
18-2 963411001410D BUTTON 3KEY B 590
5097213611000S 1
19 00D9630365002 BUTTON WIN 3KEY BK
5097213371000S 2
19 00D9630365301 BUTTON WIN 3KEY SP
5097213371110S 2
20 963411003400D BUTTON WIN 3KEY C BK
5097213831000S 1*
20 963411003690D BUTTON WIN 3KEY C SP
5097213831100S 1*
28 nsp HEAT SINK MAIN
2120211428000S 1*
31 963252004340S POSISTOR
F320121021240S 1
32 nsp BRACKET PCB
4010210186000S 5
40 00D9630214607 CUSHION FOOT
4050211295000S 4
41 963407003330D FOOT
4000210261000S 4
42 nsp CHASSIS MAIN
3200212816000S 1*
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
