Denon AVR-1610 Service Manual

78
AVR-1910/1620/1610/790/590
D1026 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1027-1029 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1030 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D1031,1032 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1033 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D1034-1036 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1037-1040 00D9600197107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
D1041,1042 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1043 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1044 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D1045 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D1046 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD1000 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD1001 00D9600128105 D,ZENER MTZJ9.1B K06009R144520S
ZD1002 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R1008 00D9630232906 R,METAL FILM 47K-F,1/4W
C060047343530S
R1010,1011 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R1015,1016 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R1019,1020 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R1096 00D9639005639 R,METAL FILM 100-J,1W C060010165060S
R1172,1173 00D9630216003 R,METAL 0.22-J,1W-R C060R22065050S
R1199C 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1199FL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1199FR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1199SL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1199SR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
CAPACITORS GROUP
C1000 00D9630224503 C,ELECT 22UF-M/50V
D040220087060S
C1000C nsp C,FILM 0.015UF-J/100V D02015306C060S
C1000FL nsp C,FILM 0.015UF-J/100V D02015306C060S
C1000FR nsp C,FILM 0.015UF-J/100V D02015306C060S
C1000SL nsp C,FILM 0.015UF-J/100V D02015306C060S
C1000SR nsp C,FILM 0.015UF-J/100V D02015306C060S
C1001 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C1002 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1003-1008 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1014 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1015 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1016 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1017 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1018 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
C1019 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1020 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
C1021 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1022 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1025 00D9639003097 C,FILM 0.1UF-K/250V D02010407H080S
C1028 00D2546276008 C,ELECT 12000UF-M/71V(VSSN) 1910, 790 D040123089020S
C1028 00D9639003107 C,ELECT 6800UF-M/63V 1610/590E3 D040682088010S
C1028 963134004220S C,ELECT 6800UF-M/75V 1610E2/E1C, 1620E1C, 590EA D04068208A000S
C1031-1033 00D9639003097 C,FILM 0.1UF-K/250V D02010407H080S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
