Denon AVR-1610 Service Manual

79
AVR-1910/1620/1610/790/590
C1034 00D2546276008 C,ELECT 12000UF-M/71V(VSSN) 1910, 790 D040123089020S
C1034 00D9639003107 C,ELECT 6800UF-M/63V 1610/590E3 D040682088010S
C1034 963134004220S C,ELECT 6800UF-M/75V 1610E2/E1C, 1620E1C, 590EA D04068208A000S
C1035 00D9639003097 C,FILM 0.1UF-K/250V D02010407H080S
C1036 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1037 nsp C,CERAMIC 100PF-J/50V 1610, 1620, 590 D010101167160S
C1038 00D9630224503 C,ELECT 22UF-M/50V 1610, 1620, 590 D040220087060S
C1039 00D9630324704 C,ELECT 4700UF-M/16V 1610, 1620, 590 D040472083200S
C1039 00D9630324704 C,ELECT 4700UF-M/16V 1910, 790 D040472083200S
C1041-1043 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1044 00D9630224503 C,ELECT 22UF-M/50V 1610, 1620, 590 D040220087060S
C1045 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C1046 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C1047,1048 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1049,1050 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C1051,1052 00D9630224503 C,ELECT 22UF-M/50V 1610, 1620, 590 D040220087060S
C1053,1054 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1055 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C1056,1057 00D9600298802 C,ELECT 470UF-M/6.3V D040471081070S
C1058-1060 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1061 nsp C,FILM 0.1UF-J/100V D02010406C060S
C1062 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C1063 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C1064 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C1065 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1066 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1067 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1068 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1069-1071 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1072,1073 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C1074 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1075,1076 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1077,1078 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1079 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1080,1081 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1082 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1083 nsp C,CERAMIC 100PF-J/50V 1610, 1620, 590 D010101167160S
C1084 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) 1610, 1620, 590 D040R10087080S
C1086 nsp C,CERAMIC 0.01UF-K/50V E2 D010103777160S
C1087 00D9639005862 C,ELECT 47UF-M/16V E2 D040470083080S
C1088 00D9630234205 C,ELECT 10UF-M/50V E2 D040100087070S
C1089 nsp C,CERAMIC 330PF-J/50V E2 D010331167160S
C1090 nsp C,CERAMIC 560PF-J/50V E2 D010561167160S
C1091,1092 nsp C,CERAMIC 27PF-J/50V E2 D010270167160S
C1093 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C1094 00D9639005804 C,ELECT 100UF-M/25V D040101084060S
C1095 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1096 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1096C nsp C,FILM 0.1UF-J/50V D020104167050S
C1096FL nsp C,FILM 0.1UF-J/50V D020104167050S
C1096FR nsp C,FILM 0.1UF-J/50V D020104167050S
C1096SL nsp C,FILM 0.1UF-J/50V D020104167050S
C1096SR nsp C,FILM 0.1UF-J/50V D020104167050S
C1097-1102 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C1103 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1104 nsp C,CERAMIC X7R4700PF-K/50V D011472777160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
