Panel trasero
Consulte la página que se indica entre paréntesis ( ).
q w e r t
y
uio
q Terminales de antena FM/AM ··············································· (10)
w Conectores de audio analógico ············································ (7, 8)
e Terminales de altavoces ······································· (C 6, 36, 37)
r Conectores S-VIDEO/VIDEO ············································ (7, 8, 9)
t Cable de alimentación ······················································ (C 5)
y Conectores HDMI ·························································· (C 3, 6)
u Conectores PRE OUT ············································ (C 6, 36, 37)
i Conectores de audio digital ················································· (7, 8)
o Conector DOCK CONTROL ······················································· (9)
NOTA
No toque los pines internos de los conectores en el panel trasero.
La descarga electrostática puede ocasionar daños permanentes a la
unidad.
