RLY104 960 0181 702 Relay (G5PA-28 24V) 1
RLY105 963 0071 303 Relay (RSB24S 24V) 1
RLY106 960 0181 605 Relay (G5PA-1-8 12V) 1
SW391 963 0045 708 Tact switch 1
SW393 963 0045 708 Tact switch 1
SW901 960 0176 209 Push switch for E3,EU 1
SW901A 963 0098 807 Push switch for E2,EK,ASIA 1
TP101 960 0161 405 3P connector base 1
TP102 960 0161 405 3P connector base 1
TP103 960 0161 405 3P connector base 1
TP104 960 0161 405 3P connector base 1
TP105 960 0161 405 3P connector base 1
VEC303 963 0095 208 Encoder SW 1
 Heat sink 1
 Heat sink 1
 963 0068 400 Capacitor cover for E2,EK,E1C,E1K 1
 963 0060 000 Fuse label(2.5A) for E2,EK,E1K 1
 963 0090 504 Fuse label(3.15A) for E1C 1
 963 0094 924 Mini trans for E3,EU 1
 963 0094 937 Mini trans for E2,EK,EA 1
 963 0094 911 Mini trans for E1C,E1K 1
 963 0094 940 Mini trans for E1,E1H,E1T 1
963 0018 007 Screw (2S 3 × 8 ZNY/BH) 3
Ref. No. Part No. Part Name Remarks
CPU P.W.B. ASS'Y
SEMICONDUCTORS GROUP
IC201 963 0102 201 IC CXP740096-161Q
IC202 963 0057 602 IC TDA7330BD for E2,EK
IC203 960 0080 201 IC KIC9164AN
IC204 963 0043 603 IC KIC9482F
IC205 960 0174 502 IC NJM2068DD
IC206 960 0174 502 IC NJM2068DD
IC207 960 0174 502 IC NJM2068DD
IC208 960 0174 502 IC NJM2068DD
IC209 960 0174 502 IC NJM2068DD
IC210 960 0174 502 IC NJM2068DD
IC301 960 0180 004 IC LC75721E
IC302 963 0074 504 IC BU2090F
IC603 960 0174 502 IC NJM2068DD
IC803 269 0186 002 IC GP1FA502RZ
RMC301 960 0181 100 IC NJL64H380A
Q201 269 0054 901 Transistor DTC144EK
Q202 963 0045 902 Transistor 2SC2412KT
Q203 269 0055 900 Transistor DTA144EK
Q204 963 0024 208 Transistor DTC114YK
Q207 960 0196 807 Transistor 2SK117Y
Q208 960 0196 807 Transistor 2SK117Y
Q209 269 0093 904 Transistor DTA144ES
Q210 269 0040 902 Transistor DTC144ES
Q216 269 0046 906 Transistor DTA114ES
Q217 963 0102 803 Transistor 2SA933S
Q218 963 0102 803 Transistor 2SA933S
Q221 269 0083 901 Transistor DTA114EK
Q300 269 0055 900 Transistor DTA144EK
Q301 269 0055 900 Transistor DTA144EK
Q302 269 0054 901 Transistor DTC144EK
Q303 269 0054 901 Transistor DTC144EK
Q304 269 0054 901 Transistor DTC144EK
Q305 269 0055 900 Transistor DTA144EK
Q306 269 0082 902 Transistor DTC114EK
Q307 963 0024 208 Transistor DTC114YK
D201 963 0096 508 Diode 1N4148
D202 963 0058 407 Diode IN4007
D204 960 0197 000 Diode KDS160
D205 960 0197 000 Diode KDS160
D206 960 0197 000 Diode KDS160 for E2,EK
D207 960 0197 000 Diode KDS160
D209 960 0197 000 Diode KDS160
D213 963 0096 508 Diode 1N4148
D214 963 0058 407 Diode IN4007
Ref. No. Part No. Part Name Remarks Q'ty
