Denon AVR-1803/883 - Exploded View Parts List Breakdown; Main P.W.B. Assy Parts

57
AVR-1803/883
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
Note: The symbols in the column “Remarks” indicate the following destinations.
E3: U.S.A. model, Canada model E1: Asia model
EU: U.S.A. model (AVR-883) E1C: China model
E2: Europe model E1H: Hong Kong model
EK: U.K. model E1T: Taiwan R.O.C. model
E1K: Korea model
963 0103 307 MAIN P.W.B ASS’Y for E3,EU 1
963 0103 310 for E2,EK 1
963 0103 323 for E1,E1H,E1T 1
963 0103 336 for E1C 1
963 0103 349 for E1K 1
10 HEAD PHONE P.W.B ASS’Y 1
11 SWITCH P.W.B ASS’Y 1
43 MAIN P.W.B ASS’Y 1
47 CDR-CNT P.W.B ASS’Y 1
75 POWER SWITCH P.W.B ASS’Y for E2,EK,ASIA 1
963 0103 404 CPU P.W.B ASS’Y for E3,EU 1
963 0103 417 for E2,EK 1
963 0103 420 for ASIA 1
12 FRONT P.W.B ASS’Y 1
50 CPU P.W.B ASS’Y 1
62 FRONT-OPTICAL P.W.B ASS’Y 1
69 FRONT-S-VIDEO P.W.B ASS’Y 1
963 0103 501 CNT P.W.B ASS’Y for E3,EU 1
963 0103 514 for E2,EK 1
963 0103 527 for E1,E1H,E1T 1
963 0103 530 for E1C,E1K 1
26 VIDEO-CNT P.W.B ASS’Y 1
35 CNT P.W.B ASS’Y 1
44 FRONT-CNT P.W.B ASS’Y 1
45 COMPONENT-VIDEO P.W.B ASS’Y 1
46 S-VIDEO P.W.B ASS’Y 1
53 TUNER P.W.B ASS’Y 1
963 0103 608 INPUT-PREAMP P.W.B ASS’Y for E3,EU 1
963 0103 611 for E2,EK 1
963 0103 624 for E1,E1C,E1H,E1T 1
963 0103 637 for E1K 1
39 OUTLET P.W.B ASS’Y for E2,EK,E1K 1
48 C-VIDEO P.W.B ASS’Y 1
51 INPUT P.W.B ASS’Y 1
56 PRE-AMP P.W.B ASS’Y 1
65 1CH-AMP P.W.B ASS’Y 1
66 PRE-AMP-CNT P.W.B ASS’Y 1
73 MULTI OUT P.W.B ASS’Y for E3,EU 1
963 0103 705 DSP P.W.B ASS’Y 1
49 DSP P.W.B ASS’Y 1
963 0103 802 VOL-SEL P.W.B ASS’Y for E1,E1H,E1T 1
74 VOLTAGE SEL P.W.B ASS’Y for E1,E1H,E1T 1
1 963 0101 215 Front panel for E3 1
963 0101 228 Front panel for EU 1
963 0101 231 Front panel for E2(Black model),EK 1
963 0101 244 Front panel for E2(Gold model) 1
963 0101 257 Front panel for ASIA 1
2 963 0101 011 Power button for Black model 1
963 0101 008 Power button for Gold model 1
3 963 0093 116 Window for E3,EU,ASIA 1
963 0093 129 Window for E2,EK 1
4 112 0839 008 Volume knob for Black model 1
112 0839 011 Volume knob for Gold model 1
5 963 0084 811 Select knob for Black model 1
963 0084 808 Select knob for Gold model 1
6 963 0051 310 Lens for E3,EU 2
963 0051 310 Lens for E2,EK,ASIA 1
7 963 0101 516 Inner panel(BK) for E3,EU 1
963 0101 529 Inner panel(BK) for E2(Black model),EK 1
963 0101 532 Inner panel(GO) for Gold model 1
8 960 0176 209 Push switch SW901 for E3,EU 1
963 0098 807 Push switch SW901A for E2,EK,ASIA 1
9 963 0095 402 Head phone jack (D6.5) JK901 1
13 960 0180 509 FLT (16-ST-42GNK) 1
14 960 0181 100 IC NJL64H380A RMC301 1
15 960 0197 204 LED PI5-RD/HL50RDRF4T LED301-309 9
16 960 0184 408 FLT holder 1
17 960 0184 301 Heat sink bracket F 1
19 963 0044 107 Transistor 2SB1560Y Q102C,FL,FR,SL,SR,SB 6
20 960 0187 900 Posistor P43T7D330BW16 1
21 963 0058 106 Transistor 2SD947F Q103C,FL,FR,SL,SR,SB 6
22 963 0044 204 Transistor 2SD2390Y Q101C,FL,FR,SL,SR,SB 6
23  Heat sink 1
24 960 0184 204 Heat sink bracket B 1
25 960 0183 205 Top cover for Black model 1
963 0055 510 Top cover for Gold model 1
28 963 0098 108 Main Chassis 1
29 960 0183 904 Foot assy 4
30 963 0051 103 Card spacer 2
31 960 0003 301 PCB supporter 2
32 960 0184 107 Supporter bracket 1
33 963 0092 609 Trans bracket 1
34 960 0184 000 Screw bracket 4
36 963 0104 005 Power trans for E3,EU 1
963 0104 018 Power trans for E2,EK 1
963 0104 021 Power trans for E1,E1H,E1T 1
963 0104 034 Power trans for E1C,E1K 1
40 960 0194 809 2P speaker terminal JK103 1
41 963 0074 009 8P speaker terminal JK102 1
42 960 0188 608 4P speaker terminal JK101 1
52 096 3009 900 Earth plate 1
54 963 0054 003 Shield tuner pack 1
55 963 0104 102 Back panel for E3 1
963 0104 115 Back panel for EU 1
963 0104 128 Back panel for E2,EK 1
963 0104 131 Back panel for E1,E1H,E1T 1
963 0104 144 Back panel for E1C 1
963 0092 751 Back panel for E1K 1
57 960 0192 403 AC cord stopper 1
