Ref. No. Part No. Part Name RemarksRef. No. Part No. Part Name Remarks
INPUT VOLUME P.W.B. ASS'Y
Q602V 269 0082 902 Transistor DTC114EK
Q603 960 0005 105 Transistor KTA1266Y
Q604 963 0102 900 Transistor DTC114TK
Q605 963 0102 900 Transistor DTC114TK
Q606 963 0075 406 Transistor DTC114TS
Q607M 960 0196 904 Transistor DTC114YS (NPN)
Q610V 269 0083 901 Transistor DTA114EK
Q611V 269 0082 902 Transistor DTC114EK
Q612V 269 0083 901 Transistor DTA114EK
Q613V 269 0082 902 Transistor DTC114EK
D106 963 0096 508 Diode 1N4148
D251 960 0197 000 Diode KDS160
D252 960 0197 000 Diode KDS160
D253 960 0197 000 Diode KDS160
D254 960 0197 000 Diode KDS160
D255 960 0197 000 Diode KDS160
D256 960 0197 000 Diode KDS160
D601 960 0197 000 Diode KDS160
D601B 963 0096 508 Diode 1N4148
D602 960 0197 000 Diode KDS160
D603 960 0197 000 Diode KDS160
D604 960 0197 000 Diode KDS160
D605 960 0197 000 Diode KDS160
D606 960 0197 000 Diode KDS160
RESISTORS GROUP
R104SB 963 9005 451 Metal oxide 5.6 kohm 1W
R105SB 963 9005 451 Metal oxide 5.6 kohm 1W
R106SB 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107SB 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R108SB 963 9005 477 Metal oxide 0.22 ohm 1W
R109SB 963 9005 477 Metal oxide 0.22 ohm 1W
R110SB 963 9005 477 Metal oxide 0.22 ohm 1W
R111SB 963 9005 477 Metal oxide 0.22 ohm 1W
R118SB 963 9005 480 Metal oxide 10 ohm 1W
R119SB 963 9005 480 Metal oxide 10 ohm 1W
R201ML 963 9004 339 Carbon chip 470 ohm 1/16W for E3,EU
R201MR 963 9004 339 Carbon chip 470 ohm 1/16W for E3,EU
R203ML 963 9004 070 Carbon chip 10 kohm 1/16W for E3,EU
R203MR 963 9004 070 Carbon chip 10 kohm 1/16W for E3,EU
R204ML 963 9004 203 Carbon chip 220 ohm 1/16W for E3,EU
R204MR 963 9004 203 Carbon chip 220 ohm 1/16W for E3,EU
R205ML 963 9004 229 Carbon chip 22 kohm 1/16W for E3,EU
R205MR 963 9004 229 Carbon chip 22 kohm 1/16W for E3,EU
R206ML 963 9004 368 Carbon chip 470 kohm 1/16W for E3,EU
R206MR 963 9004 368 Carbon chip 470 kohm 1/16W for E3,EU
R207ML 963 9004 083 Carbon chip 100 kohm 1/16W for E3,EU
R207MR 963 9004 083 Carbon chip 100 kohm 1/16W for E3,EU
SEMICONDUCTORS GROUP
IC601 963 0083 304 IC BA7626
IC602 963 0074 504 IC BU2090F
IC603 963 0083 304 IC BA7626
IC604 960 0174 502 IC NJM2068DD
IC605 960 0174 502 IC NJM2068DD
IC606 960 0133 307 IC KIC9459F
IC701 963 0083 207 IC TC9274N-011
IC702 960 0174 201 IC TC9273N-004
IC703 960 0174 502 IC NJM2068DD
IC704 960 0174 502 IC NJM2068DD
IC705 960 0174 502 IC NJM2068DD
Q101SB 963 0044 204 Transistor 2SD2390-Y
Q102SB 963 0044 107 Transistor 2SB1560-Y
Q103SB 963 0058 106 Transistor 2SD947F
Q104SB 960 0196 506 Transistor KSC1845F
Q201ML 963 0044 301 Transistor KTC2875B for E3,EU
Q201MR 963 0044 301 Transistor KTC2875B for E3,EU
Q202ML 963 0044 301 Transistor KTC2875B for E3,EU
Q202MR 963 0044 301 Transistor KTC2875B for E3,EU
Q501C 960 0196 603 Transistor KTC2874B
Q501FL 960 0196 603 Transistor KTC2874B
Q501FR 960 0196 603 Transistor KTC2874B
Q501SB 960 0196 603 Transistor KTC2874B
Q501SL 960 0196 603 Transistor KTC2874B
Q501SR 960 0196 603 Transistor KTC2874B
Q502C 960 0196 205 Transistor KSA992F
Q502FL 960 0196 205 Transistor KSA992F
Q502FR 960 0196 205 Transistor KSA992F
Q502SB 960 0196 205 Transistor KSA992F
Q502SL 960 0196 205 Transistor KSA992F
Q502SR 960 0196 205 Transistor KSA992F
Q503C 960 0196 205 Transistor KSA992F
Q503FL 960 0196 205 Transistor KSA992F
Q503FR 960 0196 205 Transistor KSA992F
Q503SB 960 0196 205 Transistor KSA992F
Q503SL 960 0196 205 Transistor KSA992F
Q503SR 960 0196 205 Transistor KSA992F
Q504C 960 0196 506 Transistor KSC1845F
Q504FL 960 0196 506 Transistor KSC1845F
Q504FR 960 0196 506 Transistor KSC1845F
Q504SB 960 0196 506 Transistor KSC1845F
Q504SL 960 0196 506 Transistor KSC1845F
Q504SR 960 0196 506 Transistor KSC1845F
Q601 960 0005 105 Transistor KTA1266Y
Q601V 269 0083 901 Transistor DTA114EK
Q602 960 0005 105 Transistor KTA1266Y
