Denon AVR-1906 Service Manual

44
AVR-1906 / AVR-786 / AVC-1620
C903 nsp 00D 963 0233 109 C,CERAMIC 0.01UF-Z/50V *
C904 nsp 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V
C905 nsp 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
OTHERS PARTS GROUP
! F102 00D 960 0194 906 FUSE 125V-S8A JP
! F102 00D 963 0104 801 FUSE T3.15A /250V BKE2,SRE2,E2A,E1K
! F102 00D 963 0236 106 FUSE T8A/250V BKE3,SRE3,EUT
F102A nsp 00D 960 0005 804 HOLDER,FUSE CLIP
F102B nsp 00D 960 0005 804 HOLDER,FUSE CLIP
G101 nsp 00D 960 0260 005 CLAMP *
G903 - RING,TER WIRE *
GND101-103 - TERMINAL
L101C nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101FL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101FR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
RLY101-104 00D 960 0181 702 RELAY G5PA-28 24V 5A
RLY105 00D 963 0218 506 RELAY BC3-24 24V 2A *
RLY107 00D 960 0181 702 RELAY G5PA-28 24V 5A
SW341A 00D 963 0200 103 SW,TACT SKHV10920A
SW342A 00D 963 0200 103 SW,TACT SKHV10920A
SW901 00D 963 0200 103 SW,TACT SKHV10920A
TP101-105 nsp 00D 960 0161 405 CN.WAFER 53014-0310 3P
VEC303 00D 963 0095 208 SW,ENCODER EC16B24SA
CN901 nsp 00D 963 0184 601 CN,WIRE 260MM/3P *
CN992 nsp 00D 963 0235 602 CN,WIRE 270MM/4P *
CP101 nsp 00D 960 0118 908 CN.WAFER
CP102 nsp 00D 960 0123 304 CN.WAFER
CP103 nsp 00D 963 0066 208 CN.WAFER
CP104 nsp 00D 960 0128 804 CN.WAFER 6P
CP105 nsp 00D 963 0149 109 CN.WAFER 2P *
CP106 nsp 00D 960 0123 207 CN.WAFER 3P
CP138A nsp 00D 960 0123 207 CN.WAFER 3P
CP302 nsp 00D 963 0160 900 CN.WAFER 8P *
CP392 nsp 00D 963 0235 806 CN.WAFER 3P
CP501 nsp 00D 963 0206 505 CN.WAFER 9P
CP502 nsp 00D 963 0206 408 CN.WAFER 7P
CP503-504 nsp 00D 963 0206 301 CN.WAFER 5P
CP505 nsp 00D 963 0235 709 CN.WAFER 12P
CP555-556 nsp 00D 963 0087 805 CN.WAFER 11P
CP901 nsp 00D 963 0235 806 CN.WAFER 3P
CP931 nsp 00D 963 0149 206 CN.WAFER 2P *
! * 00D 963 0232 003 POWER TRANS STAND BY JP *
! * 00D 963 0232 100 POWER TRANS STAND BY BKE3,SRE3,EUT *
! * 00D 963 0215 606 POWER TRANS STAND BY BKE2,SRE2,E2A *
! * 00D 963 0232 207 POWER TRANS STAND BY E1K *
* nsp 00D 963 0018 007 SCREW 3*8 B-TYPE ZNY/BH
* 00D 963 0158 608 TER,BOARD SCREW 2P
* 00D 963 0119 906 TER,BOARD SCREW 8P
* 00D 963 0119 906 TER,BOARD SCREW 8P
* 00D 963 0119 906 TER,BOARD SCREW 8P
* 00D 963 0095 402 JACK PHONE D6.5
* - COVER CAPACITOR E2,E2A,EUT,E1K,JP *
* nsp 00D 963 0120 500 LABEL F102 T3.15AL/250V BKE2,SRE2,E2A,EUT,E1K *
* nsp 00D 963 0120 526 LABEL F102 T8A JP *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
