Denon AVR-1906 Service Manual

57
AVR-1906 / AVR-786 / AVC-1620
R771-772 00D 963 9005 639 R,METAL 100-J,1W
R79-792 00D 963 9005 639 R,METAL 100-J,1W
CAPACITORS GROUP
C1-3 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C601 nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V *
C601A nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C602 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C602A nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
C603 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C603A nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C605A nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C606 nsp 00D 963 0157 706 C,CERAMIC 0.022UF-K/50V *
C606A-607A nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V BKE3
C607 nsp 00D 963 9005 862 C,ELECT 47UF-M/16V *
C608 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C609 nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V *
C610 nsp 00D 963 9005 998 C,CERAMIC 24PF-J/50V
C611 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C612 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C613 nsp 00D 963 9005 998 C,CERAMIC 24PF-J/50V
C614 nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C615 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C616 nsp 00D 963 0129 909 C,CERAMIC 1200PF-K/50V *
C617 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C618 nsp 00D 963 0157 706 C,CERAMIC 0.022UF-K/50V *
C619 nsp 00D 963 9005 862 C,ELECT 47UF-M/16V *
C620 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C621 nsp 00D 963 9005 862 C,ELECT 47UF-M/16V *
C622-623 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C624-625 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C626-627 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C628 nsp 00D 963 9006 117 C,ELECT 2.2UF-M/50V *
C629 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C630 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C633 nsp 00D 963 0244 606 C,ELECT 0.1UF-M/50V
C634 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C634V nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C635 nsp 00D 963 0244 606 C,ELECT 0.1UF-M/50V
C636-637 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C638 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C639 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
C640 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C641 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C642-643 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C644 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C645 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C646 nsp 00D 963 9006 117 C,ELECT 2.2UF-M/50V *
C647 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V
C648 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C649-650 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V
C657 nsp 00D 963 0144 609 C,CERAMIC 12PF-J/50V *
C658 nsp 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C659 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C660 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C662 nsp 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C663 nsp 00D 963 0144 609 C,CERAMIC 12PF-J/50V *
C664 nsp 00D 960 9010 023 C,ELECT 0.47UF-M/50V *
C670 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C670SC nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C671-672 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C671SC nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C673 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
C674 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C680 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C681 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
