Denon AVR-1906 Service Manual

59
AVR-1906 / AVR-786 / AVC-1620
C781SBR nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C781SL nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C781SR nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C781SW nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C782C nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C782SBL nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C782SBR nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C782SW nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C782FL nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C782FR nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C782SL nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C782SR nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C783C nsp 00D 963 0223 902 C,CERAMIC 39PF-J/50V *
C783SBL nsp 00D 963 0223 902 C,CERAMIC 39PF-J/50V *
C783SBR nsp 00D 963 0223 902 C,CERAMIC 39PF-J/50V *
C783SL nsp 00D 963 0223 902 C,CERAMIC 39PF-J/50V *
C783SR nsp 00D 963 0223 902 C,CERAMIC 39PF-J/50V *
C783FL nsp 00D 963 0246 604 C,CERAMIC 56PF-J/50V *
C783FR nsp 00D 963 0246 604 C,CERAMIC 56PF-J/50V *
C783SW nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C786SW nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C791-792 nsp 00D 963 9005 875 C,ELECT 47UF-M/25V *
C793-795 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C795 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C795 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C796-797 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
OTHERS PARTS GROUP
BD601-602 nsp 00D 963 0234 603 COIL,BEAD MB-160808-0120H
BD604 nsp 00D 963 0234 603 COIL,BEAD MB-160808-0120H
CN551A nsp 00D 963 0245 508 CN,WIRE 160MM/15P *
CN601 nsp 00D 963 0110 701 CN.WAFER 14P
CN602 nsp 00D 963 0086 505 CN.WAFER 7P
CN603 nsp 00D 963 0086 107 CN.WAFER 16P
CN701M nsp 00D 963 0245 809 CN,WIRE 5P *
CN703 nsp 00D 963 0085 506 CN.WAFER 9P
CN704 nsp 00D 963 0097 206 CN.WAFER 8P
CN70-702 nsp 00D 963 0086 204 CN.WAFER 19P
CP551B nsp 00D 963 0066 101 CN.WAFER 5P
L601 nsp 00D 963 0115 609 COIL INDUCTOR 33UH-Q40/14M *
L602-604 nsp 00D 963 0145 200 COIL INDUCTOR 27UH-Q40/16M *
L605-606 nsp 00D 960 0128 008 COIL INDUCTOR 100UH-Q40/9M
L607 nsp 00D 963 0145 103 COIL INDUCTOR 22UH-Q50/9.6M *
L608 nsp 00D 960 0128 008 COIL INDUCTOR 100UH-Q40/9M
RLY701-702 00D 963 0218 409 RELAY BC3-12 24V 2A *
* nsp 00D 963 0094 005 CUSHION EVA 24*18*2.7t *
* nsp 00D 963 0094 102 PLATE INPUT *
* 00D 963 0146 209 TER,RCA 4PIN *
* 00D 960 0268 803 TER,RCA 6PIN
* 00D 963 0158 501 TER,RCA 2PIN BKE3 *
* 00D 963 0218 001 TER,RCA 2PIN *
* 00D 963 0218 108 TER,RCA 3PIN *
* 00D 963 0158 200 JACK,D3.5 (MIC) *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
