Denon AVR-1906 Service Manual

64
AVR-1906 / AVR-786 / AVC-1620
C902 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C903-904 nsp 00D 963 9006 117 C,ELECT 2.2UF-M/50V *
C905 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C906 nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C907 nsp 00D 963 0234 205 C,ELECT 10UF-M/50V *
C908 nsp 00D 960 9009 924 C,ELECT 100UF-M/16V
C909 nsp 00D 963 0144 706 C,FILM 0.01UF-J/50V *
C910 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
C911 nsp 00D 963 0144 609 C,CERAMIC 12PF-J/50V *
C912 00D 963 0141 709 C,FILM 0.022UF-J/50V *
C913 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C914 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C915 nsp 00D 960 9009 924 C,ELECT 100UF-M/16V
C916 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V *
C917 00D 963 0144 900 C,FILM 0.0022UF-J/50V *
C918-923 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V
C924 nsp 00D 960 9009 924 C,ELECT 100UF-M/16V
C925 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C926C nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926FL nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926FR nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926SBL nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926SBR nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926SL nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926SW nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C926SW nsp 00D 963 9006 544 C,ELECT 22UF-M/25V *
C929 00D 963 0199 308 C,FILM 1UF-J/63V *
C929C nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C929FL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C929FR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C929SBL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C929SBR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C929SL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C926SW nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C926SW nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C930 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V
C931-932 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V
C933-934 00D 963 0234 108 C,FILM 0.1UF-J/50V *
C935 00D 963 0144 706 C,FILM 0.01UF-J/50V *
OTHERS PARTS GROUP
CN401 nsp 00D 963 0236 902 CN.WAFER 12P
CN402 nsp 00D 963 0097 303 CN.WAFER 15P
CN403 nsp 00D 963 0149 303 CN.FPC 15P *
CN604 nsp 00D 963 0086 107 CN.WAFER 16P
CN901 nsp 00D 963 0086 107 CN.WAFER 16P
CN902A nsp 00D 963 0245 605 CN,WIRE 15P *
CN902B nsp 00D 963 0245 702 CN,WIRE 5P *
CP603-604 nsp 00D 963 0087 407 CN.WAFER 16P
CP651 nsp 00D 963 0087 407 CN.WAFER 16P
RLY901-908 00D 963 0218 302 RELAY BC3-6 24V 2A *
* 00D 963 0244 703 JACK,D3.5 *
* 00D 960 0268 803 TER,RCA 6PIN
* 00D 963 0132 103 TER,RCA 4PIN *
* 00D 963 0146 306 TER,RCA 6PIN *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
