Denon AVR-1906 Service Manual

77
AVR-1906 / AVR-786 / AVC-1620
14 nsp 00D 963 0110 303 COLOR LABEL(SILVER) SRE3/SRE2 2
14 nsp 00D 963 0230 209 COLOR LABEL(PREMIUM SILVER) E2A/EUT/E1K 2
! 19 00D 963 0160 706 CORD ASSY JP 1
20 00D 321 0038 005 MIC DM-S205 1 *
* nsp - LICENSE (DOLBY/DTS)LABEL 1
* nsp - SERIAL NO. LABEL 1
* nsp - NOTICE SHEET JP 1 *
* nsp - CUSHION JP 1 *
* nsp - LABEL EUT 1 *
* nsp - KORIN LABEL EUT 1 *
* nsp - LABEL ORIGIN EUT 1 *
* nsp - RATING LABEL EUT 1 *
* nsp - LABEL ORIGIN EUT 1 *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
