8
AVR-1906 / AVR-786 / AVC-1620
714±50mV
p-p
Vo l ts
IRE:FLT
Y-Signal
-20.0 -10.0 0.0
10.0
20.0 30.0
0.5
0.0
100.0
0.5
40.0 50.0 60.0
486±50mV (U.S.A. & Canada model)
p-p
525±50mV (Other model)
p-p
Volts
IRE:FLT
0.0
20.0
40.0
-0.5
-50.0
50.0
0.0
0.5
0.0
60.0
80.0
486±50mV (U.S.A. & Canada model)
p-p
Vo l ts
IRE:FLT
0.0
20.0
40.0
-0.5
-50.0
50.0
0.0
0.5
0.0
60.0
80.0
Fig.1 Component Video Y signal
Fig.2 Cb signal
Fig.3 Cr signal
50.0
525±50mV (Other model)
p-p

Other manuals for Denon AVR-1906

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-1906 and is the answer not in the manual?

Denon AVR-1906 Specifications

Power Amplifier Section IconPower Amplifier Section
front power output (8 ohms)85 W + 85 W
front power output (6 ohms)120 W + 120 W
center power output (8 ohms)85 W
center power output (6 ohms)120 W
surround power output (8 ohms)85 W + 85 W
surround power output (6 ohms)120 W + 120 W
surround back power output (8 ohms)85 W + 85 W
surround back power output (6 ohms)120 W + 120 W
Preamplifier Section IconPreamplifier Section
input sensitivity/impedance200 mV/47 kohms
output level/load impedanceSUBWOOFER 1.2 V/10 kohms
frequency response10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio98 dB (IHF-A weighted)
tone control treble±12 dB at 10 kHz
tone control bass±12 dB at 100 Hz
FM Section IconFM Section
tuning frequency range (FM)87.5 - 107.9 MHz
usable sensitivity (FM)1.0 µV (11.2 dBf)
AM Section IconAM Section
tuning frequency range (AM)520 - 1710 kHz
usable sensitivity (AM)18 µV
General IconGeneral
power supplyAC 120 V, 60 Hz
power consumption5.1 A
dimensions434 (W) x 147 (H) x 417 (D) mm
weight11.7 kg
