79
AVR-1907 / AVR-787 / AVC-1630
31 - BRACKET TRANS 4010210466002S 1
! 32 00D 963 0299 907 POWER TRANS MAIN 1907E3,787E3 8200960660090S 1 *
! 32 00D 963 0300 003 POWER TRANS MAIN 1907E2,E2A 8200960660120S 1 *
! 32 00D 963 0302 001 POWER TRANS MAIN 1907EUT 8200960660100S 1 *
! 32 00D 963 0302 108 POWER TRANS MAIN 1907E1K 8200960660110S 1 *
! 32 00D 963 0300 100 POWER TRANS MAIN 1630JP 8200960660130S 1 *
38 nsp 00D 963 0292 506 CHASSIS MAIN 3200210146305S 1
39 nsp 00D 963 0137 904 FOOT 4007210261000S 4
40 nsp 00D 963 0191 403 CUSHION SIDE 4050211095000S 2
! 41 nsp 00D 963 0158 404 AC INLET 1630JP G430040560020S 1
42 nsp 00D 960 0003 301 SUPPORTER PCB 4070001601010S 4
43 - BRACKET SUPPORTER 4010210206000S 1
44 - SUPPORTER P.C. 4070210192000S 1
45 00D 963 0145 608 TUNER,FM/AM 1907E3,787E3 E903014000020F 1
45 00D 216 0125 001 TUNER,FM/AM 1907E2,E2A,E1K,EUT 1
48 nsp 00D 963 0296 308 CHASSIS BACK 1907E3 3207211826400S 1 *
48 nsp 00D 963 0296 405 CHASSIS BACK 787E3 3207211826500S 1 *
48 nsp 00D 963 0296 502 CHASSIS BACK 1907E2,E2A 3207211826600S 1 *
48 nsp 00D 963 0302 205 CHASSIS BACK 1907EUT 3207211826800S 1 *
48 nsp 00D 963 0302 302 CHASSIS BACK 1907E1K 3207211826700S 1 *
48 nsp 00D 963 0296 803 CHASSIS BACK 1630JP 3207211826900S 1 *
50 nsp 00D 960 0192 403 STOPPER CORD AC 4380210002000S 1
! 51 00D 963 0301 109 AC CORD ASSY 1907E3,787E3 L068125100020S 1 *
! 51 00D 963 0292 409 AC CORD ASSY 1907E2,E2A L068250250040S 1
! 51 00D 963 0302 409 AC CORD ASSY 1907EUT L068125110000S 1 *
! 51 00D 963 0302 506 AC CORD ASSY 1907E1K L068250250050S 1 *
74 - SUPPORTER PCB 4077210941000S 1
75 nsp 00D 963 0214 607 CUSHION FOOT 4050211295000S 4
76 nsp 00D 963 9004 012 FELT STRIP 2690040057010S 2
77 - BRACKET SIDE L/R 4010211986000S 2
78 nsp 00D 963 0192 703 COVER SAFETY 1907E2,E2A,E1K,EUT 4310212122000S 1
79 nsp 00D 449 0139 105 COVER HOLDER 1907E2,E2A,E1K,EUT 6
80 - BRACKET SIDE 1907E2,E2A,E1K,EUT 4010210686000S 2
83 nsp 00D 963 0193 003 CABLE,FLAT CARD 1.25MM
1.25*15*150
Except for 1630JP N712151544811S 1
84 nsp 00D 963 0161 501 CABLE,FLAT CARD 1.25MM
1.25*23*200
N712232034810S 1
A nsp 00D 963 0018 007 SCREW,TAP TITE +2S 3*8 B-
TYPE ZNY/BH
B020030081B10S 75
B nsp 00D 960 9008 420 SCREW +2S 3*8 ZnY
WASHER PI12
1500001456010S 4
C nsp 00D 963 0232 702 SCREW,TAP TITE +3S 4*6 S-
TYPE ZNY/BH
B020740061B10S 6
D nsp 00D 960 0108 701 SCREW,TAP TITE +2S 3*10
B-TYPE(DOT) BK/BH
B020030103B11S 43
E nsp 00D 963 9006 175
SCREW +2S 3*14 P(
Φ6)
+S-WASHER ZNY/HH
B018230141H11S 22
F nsp 00D 963 0018 104 SCREW,TAP TITE +2S 3*17
B-TYPE ZNY/BH
B020030171B10S 4
G nsp 00D 963 0048 307 SCREW +2S 4*8 B-
TYPE(DOT) BK/BH
1500040083B10S 6
G nsp 00D 963 9004 012 SCREW +2S 4*8 B-
TYPE(DOT) NI/BH
Silver,Premium Silver 1500040084B10S 6
H nsp 00D 960 9009 610 SCREW,TAP TITE +3S 4*10
P+S-WASHER ZNY/BH
B028940101B10S 4
J nsp 00D 963 9004 054 SCREW,TAP TITE +2S 3*15
B-TYPE ZNY/BH
B020030151B10S 2
K nsp 00D 963 0232 605 SCREW,TAP TITE +2S 3*5 B-
TYPE ZNY/BH
1907E2,E2A,E1K,EUT B020030051B10S 2
L nsp 00D 963 9006 735 SCREW,TAP TITE +2S 3*10
B-TYPE BK/FH
1630JP B020030103F10S 2
M nsp 00D 963 9004 067 SCREW,TAPPING +2S 3*10
BK/PH
1630JP B010230103P10S 8
* nsp 00D 513 3333 005 LABEL (TRANS) 1
* nsp 00D 963 0193 207
LABEL RATING FUSE CAUTION
5527042410030S 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
