12
AVR-1908 / AVR-788
5. TRANS
(1) Disconnect the connector wires and remove the screws.（コネクタコードとねじをはずす。）
Proceeding (手順) : CABINET TOP → TRANS
Wire clamp band
Cord holder
CP104
CP402
CP402
CP302
CP105
CUT
Picture E
Please refer to
"EXPLODED VIEW"
for the disassembly method of Trans.
Trans のはずしかたは "EXPLODEDVIEW" を参照してください。
