Denon AVR-1911 Service Manual

133
Ref. No. Part No. Part Name Remarks Q'ty New
C2 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C3,4 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C5 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C6 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C7 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C8,9 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C10 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C11,12 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C13 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C14 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C15 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C16,17 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C18 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C19 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C22 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C25 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C27 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C30 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C33 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C36 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C39 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C42,45 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C53 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C54 nsp C,FILM 0.1UF-K/250V D02010407H080S
C55 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C57 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C58 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C60 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C61 nsp C,FILM 0.1UF-K/250V D02010407H080S
C63 nsp C,CERAMIC 1000PF-K/50V D011102777160S
z
C100 963132010140S C,CERAMIC ECQU2A104ML 0.1UF D00810408H000S
C102 963134010200S C,ELECT 100UF-M/400V
D04110108K000S
C103 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
z
C104,105 963132010160S C,CERAMIC DE1B3KX471KB5B D00847107H010S
C106-108 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C110 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C111 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C112 963134010190S C,ELECT 10UF-M/50V D041100087050S
C113 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C115 963132010150S C,CERAMIC DE1E3KX222MB5BA01 D00822208H010S
C116 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C117 963132010130S C,CERAMIC DE2F3KH103MB3B AC250V D008103089010S
C118 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C119 963134010210S C,ELECT 47UF-M/25V D041470084050S
C120-123 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
OTHERS PARTS GROUP
BKT1-3 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT100 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT101 nsp BRACKET SCREW 4010210196000S
CLAMP3 nsp CLAMP WIRE(SOLDER) 4330000120000S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
