Denon AVR-1911 Service Manual

134
Ref. No. Part No. Part Name Remarks Q'ty New
CN1 nsp CN,WIRE 230MM/5P L000231052050S
CN2 nsp CN,WIRE 670MM/2P L000671020010S
CN3 nsp CN,WIRE 2MM 170MM/10P L002171102620S
CP1 nsp CN.WAFER 3CKT L108353280360S
CP12 nsp CN.FPC 1.25MM 19P L131019100010S
CP22 nsp CN.WAFER 5P L101100040510S
CX100 nsp CN.WAFER 7.92MM 1911E3, 1911E1C, 791E3 L108202000220S
CX102 nsp CN.WAFER 7.92MM L108353280290S
CX104 nsp CN.WAFER 5P L101100030510S
CX105 nsp CN,WIRE 370MM/5P L000371050010S
z
F100 963652010510S FUSE T2A/250V 1911E3,791E3 N751502001160S *
z
F100 963652010500S FUSE T1.6A/250V 1911E2,1911E1C,791EA N751501601160S *
z
F101 963652010520S FUSE T6.3A/250V 1911E3,791E3 N751506301160S *
z
F101 963652010910S FUSE T3.15A/250V 1911E2, 1911E1C, 791EA N751503151160S
JACK1 963643010360S 6P JB-602A-02 G613602A0200YS
JACK2 963646001690S 8P SPEAKER TERMINAL G614108V1010MS
z
JK100 963641011240S SOCKET,POWER AC 1911E2,791EA G4300152P0001S
L1-7 nsp COIL INDUCTOR 0.5UH D330R50000000S
z
L100 963111010230S COIL LINE FILTER LF-4ZB-E273H 27mH D320402730020S
z
RL101 963682010370S RELAY HL31-1AT-5H 5V 1A G680050102020S *
RLY1 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY2-5 963682002440S RELAY 12V 5A SPK G680120502050S
z
T100 963102010240S TRANS,SWITCHING ST-4430A E060044300010S *
WIRE5 nsp CN,WIRE 900MM/2P L000901020010S
nsp HOLDER,FUSE CLIP F100_1 G645000050010S
nsp HOLDER,FUSE CLIP F100_2 G645000050010S
nsp HOLDER,FUSE CLIP F101_1 G645000050010S
nsp
HOLDER,FUSE CLIP F101_2 G645000050010S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
