Denon AVR-1911 Service Manual

135
PCB REG_CNT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1 963239001880S IC AZ4580M 1911E3 J121458000020S
IC103 00D2630553006 IC NJM7805FA J126780500130S
IC104 00D2630554005 IC NJM7905FA J126790500020S
IC105 00D2630553006 IC NJM7805FA J126780500130S
IC106 00D2630810008 IC NJM7808FA J126780800030S
IC107 00D2630503001 IC NJM7908FA J126790800020S
IC108 963239003420S IC NJM2388F05 791E3 J126238800050S
IC108 963239010770S IC NJM2388F09 1911E2,1911E1C,791EA J126238800090S
IC109 nsp IC PQ033DNA1ZPH 1911E3 J126033010010S
D114 00D9630236504 D,SWITCHING RB721Q-40 K120072140010S
D115,116 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D117,118 00D9630236504 D,SWITCHING RB721Q-40 K120072140010S
D119-121 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D122 00D9630236504 D,SWITCHING RB721Q-40 K120072140010S
D123 00D2760401905 D,SWITCHING 1SS133T 1911E2,1911E1C,791E3,791EA K000013300520S
D124,125 00D9630328409 D,SWITCHING 1N4007 1911E2,1911E1C,791EA K000400700010S
D127-134 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D137-145 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD117,118 00D9600096004 D,ZENER MTZJ33B K06033R044520S
CAPACITORS GROUP
C61 nsp C,CERAMIC 33PF-J/50V 1911E3 D010330167160S
C62,63 00D9630234205 C,ELECT 10UF-M/50V 1911E3 D040100087070S
C64 nsp C,CERAMIC 33PF-J/50V 1911E3 D010330167160S
C65 nsp C,CERAMIC 0.1UF-K/50V 1911E3 D011104577160S
C66 nsp C,CERAMIC 1UF-K/16V 1911E3 D011105173161S
C67 nsp C,CERAMIC 33PF-J/50V 1911E3 D010330167160S
C68,69,70 00D9630234205 C,ELECT 10UF-M/50V 1911E3 D040100087070S
C71 nsp C,CERAMIC 0.1UF-K/50V 1911E3 D011104777200S
C72 nsp C,CERAMIC 33PF-J/50V 1911E3
D010330167160S
C73 nsp C,CERAMIC 1UF-K/16V 1911E3 D011105173161S
C74 nsp C,CERAMIC 0.1UF-K/50V 1911E3 D011104577160S
C75 00D9630234205 C,ELECT 10UF-M/50V 1911E3 D040100087070S
C76,77,78 nsp C,CERAMIC 100PF-J/50V 1911E3 D010101167160S
C79 nsp C,CERAMIC 0.1UF-K/50V 1911E3 D011104577160S
C80,81 00D9630234205 C,ELECT 10UF-M/50V 1911E3 D040100087070S
C126 00D9630217002 C,ELECT 3300UF-M/16V
1911E3,1911E2,1911E1C,791EA D040332083010S
C126 963134011290S C,ELECT 4700UF-M/16V 791E3 D040472083020S
C127,128 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C129 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C130 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C131 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C132 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C133 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C134 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C135 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C136 00D9630333203 C,ELECT 100UF-M/16V 1911E2,1911E1C,791E3,791EA D040101083090S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
