Denon AVR-1911 Service Manual

138
Ref. No. Part No. Part Name Remarks Q'ty New
C119 nsp C,FILM 0.1UF-K/250V D02010407H080S
C120 nsp C,CERAMIC 330PF-J/50V D010331167160S
C121 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C122 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C123 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C124-126 nsp C,CERAMIC 100PF-J/50V D010101167160S
C127 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C129 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C130 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C131 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C132 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C133 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C134 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C137 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C139 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C142 nsp C,FILM 0.047UF-J/100V D02047306C060S
C143,144 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C145 nsp C,FILM 0.047UF-J/100V D02047306C060S
C146 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C147 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C148,149 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C150 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C151 nsp C,ELECT 47UF-M/16V D040470083080S
C152 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C153 nsp C,FILM ST-0.01UF-J/100V D02010306C060S
C154 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C155 nsp C,FILM ST-0.01UF-J/100V D02010306C060S
C156,157 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C158 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C159 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C160 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C161 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C163 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C164 nsp C,ELECT 220UF-M/6.3V D040221081070S
C165 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C166 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C168,169 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
OTHERS PARTS GROUP
BD100-104 nsp R,THICK 0-J,1/16W C20000006M160S
BD105 nsp COIL,BEAD CBW160808U121T D340160811210S
BD106-109 nsp R,THICK 0-J,1/16W C20000006M160S
BD110 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
BD111-112 nsp COIL,BEAD BLM18AG121SN1D D340160831211S
CB100,101 nsp R,THICK 0-J,1/16W C20000006M160S
CLAMP111 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP114 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP116 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN100 nsp CN,WIRE 2MM 130MM/5P L002131050010S *
