Denon AVR-1911 Service Manual

139
Ref. No. Part No. Part Name Remarks Q'ty New
CN102 nsp CN,WIRE 2MM 450MM/5P L002451050120S *
CP100 nsp CN.WAFER 5P L101200100510S
CP100_1 nsp 5268-07A 7P ANGLE L102526800700S
CP102 nsp CN.WAFER 2.0MM 8P L101100030810S
CP103,104 nsp CN.WAFER 8P L101100040810S
CP105 nsp CN.WAFER 2.0MM 8P L101100030810S
G101 nsp RING,TER WIRE 100MM/1P 8410101010240S
JACK100 00D9630367802 JACK,D3.5 EARPHONE G401PJ354H40YS
JACK101 963649010300S CN,PLUG DIP4P BK USBAS-00401B014-G G480040101410S *
JACK102 00D9630146403 TER,RCA 3PIN G606308HG110YS
JK100 00D9630294708 JACK,D6.5 PHONE G402PJ612AG0YS
L100 nsp COIL INDUCTOR 100UH D330101001020S
RMC100 963262010290S MODULE,REMOCON R34FS9A E940349003810S
SW100-123 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
VEC100,101 00D9630387408 SW,ENCODER EC16B24SO G121162400070S
U1 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P L130100114050S *
U100 963172010470S DISPLAY,FLT 18-ST-13GINK K530180130010S
JP209-213 nsp R,CHIP 0-J,1/8W C200000061300S
nsp HOLDER FLT 4320200026000S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
