Denon AVR-1913 Service Manual

199
VIDEO PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC5000 232810005504S IC BD7628F-E2 J127762800010S
IC5001 963239100770S IC,LOGIC TC4051BF SINGLE 8CH J040405101110S
IC5002 963239003470S IC NJM2586AM J171258600010S
CAPACITORS GROUP
C5000 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5001 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5002,5003 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5004 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5006,5007 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5011 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5012 nsp C,CERAMIC 68PF-J/50V D010680167160S
C5013,5014 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C5015,5016 nsp C,CERAMIC 68PF-J/50V D010680167160S
C5017,5018 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C5019,5020 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C5021 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C5022 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5048 nsp C,FILM 0.1UF-J/50V D020104167050S
C5051 nsp C,FILM 0.1UF-J/50V D020104167050S
OTHERS PARTS GROUP
BKT5000,5001 nsp BRACKET 0.8t/SCREW 4010210196100S
CN4001 nsp CN,WAFER C125Z2-13 L109012521320S
CN4002 nsp CN,WAFER C125Z2-15 L109012521520S
CN5000,5001 nsp CN,WAFER C125Z2-13 L109012521320S
CN5002 nsp CN,WAFER C125Z2-15 L109012521520S
CP3401 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP3402 nsp CN,WAFER C125Z1-09 9P L109012510920S
CP3404 nsp CN,WAFER C125Z1-07 7P L109012510720S
CP5000,5001 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP5003 nsp CN.WAFER 2.5MM 8P L102526808010S
z
F5001 963652010500S FUSE T1.6A/250V N751501601160S
F5001A nsp HOLDER,FUSE CLIP G645000050010S
F5001B nsp HOLDER,FUSE CLIP G645000050010S
z
F5002 963652010500S FUSE T1.6A/250V N751501601160S
F5002A nsp HOLDER,FUSE CLIP G645000050010S
F5002B nsp HOLDER,FUSE CLIP G645000050010S
z
F5003 963652010500S FUSE T1.6A/250V N751501601160S
F5003A nsp HOLDER,FUSE CLIP G645000050010S
F5003B nsp HOLDER,FUSE CLIP G645000050010S
z
F5004 963652010500S FUSE T1.6A/250V N751501601160S
F5004A nsp HOLDER,FUSE CLIP G645000050010S
F5004B nsp HOLDER,FUSE CLIP G645000050010S
JACK5000 963643101620D TER,RCA 3PIN RCA-303B1-01 G606303B1010YS

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
