Denon AVR-1913 Service Manual

205
Ref. No. Part No. Part Name Remarks Q'ty New
CN4003 nsp
CN,WAFER C125Z2-11 11P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521120S
CN4004 nsp
CN,WAFER C125Z2-17 17P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521720S
CN4700 nsp CN,WAFER 9P C125Z2-09 2113CIE3 L109012520920S
CN4701 nsp CN.WAFER 13P C125Z2-13 2113CIE3 L109012521320S
CP4200 nsp CN,WAFER C125Z1-23 23P L109012512320S
CP4201 nsp CN.WAFER C125Z1-31 31P L109012513120S
CP4202 nsp CN,WAFER C125Z1-15 15P L109012511520S
CP4203 nsp CN,WAFER C125Z1-07 7P L109012510720S
JACK4200,4201 00D9630132103 TER,RCA 4PIN RCA-405B-04 G602405B0400YS
JACK4202 90M-YT004640R TER,RCA 2PIN RCA-207AE-02 2113CIE3 G601207AE020YS

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
