Denon AVR-1913 Service Manual

207
Ref. No. Part No. Part Name Remarks Q'ty New
R1017,1018 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1019-1021 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1024-1032 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1033,1034 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1036 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1037 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1039 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1041 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1043 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1045 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1202 nsp R,CHIP 0-J,1/16W C20000006M101S
R1204 nsp R,CHIP 0-J,1/16W C20000006M101S
R1205 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1207,1208 nsp R,CHIP 0-J,1/16W C20000006M101S
R1210,1211 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1212,1213 nsp R,CHIP 0-J,1/16W C20000006M101S
R1217 nsp R,CHIP 0-J,1/16W C20000006M101S
R1301,1302 nsp R,CHIP THICK 24-D,1/16W-1608REEL C20002401M160S
R1303 nsp R,CHIP 0-J,1/16W C20000006M101S
R1305 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1306-1309 nsp R,CHIP THICK 24-D,1/16W-1608REEL C20002401M160S
R1310 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1311,1312 nsp R,CHIP 0-J,1/16W C20000006M101S
R1313 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1314,1315 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1317 nsp R,CHIP 0-J,1/16W C20000006M101S
R1318 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R1319,1320 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1323 nsp R,CHIP THICK 680-J,1/16W-1005REEL C20006816M101S
R1329 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1331 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1333 nsp R,CHIP THICK 680-J,1/16W-1005REEL C20006816M101S
R1334,1335 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1336-1338 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1339,1340 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1342-1344 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1345 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1350 nsp R,CHIP THICK 0-J,1/10W C200000060200S
R1352 nsp R,CHIP THICK 470-D,1/16W-1608REEL C20004711M160S
R1358,1359 nsp R,CHIP 0-J,1/16W C20000006M101S
R1360 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1401,1402 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1403,1404 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R1405,1406 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1407-1409 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R1410-1412 nsp R,NETWORK A-TYPE 47K-J 1/16W C180473042100S
R1413-1417 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R1418,1419 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1617,1618 963122500030D R,CHIP THICK 1K-D,1/16W-1608REEL C20001021M160S
R1619,1620 nsp CHIP RES. 1K-D 1/16W-1608REEL 1913E3 C20001021M161S
R1619,1620 nsp CHIP RES. 470-D 1/16W 1608REEL
2113CIE3, 2113E2,
2113E1C
C20004711M161S
R1622 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1628 nsp R, CHIP 2.7K-F, 1/16W
2113CIE3, 2113E2,
2113E1C
C20002724M161S
R1629 nsp CHIP RES. 180-F,1/16W-1608REEL
2113CIE3, 2113E2,
2113E1C
C20001814M161S
R1630 nsp R, CHIP 2.7K-F, 1/16W
2113CIE3, 2113E2,
2113E1C
C20002724M161S

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
