Denon AVR-1913 Service Manual

220
Ref. No. Part No. Part Name Remarks Q'ty New
OTHERS PARTS GROUP
L1201-1203 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L1301-1313 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1602 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1605-1615 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1616 nsp COIL,BEAD BLM21PG221SN1 1913E3 D340201212210S
L1617-1619 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1801 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2601-2603 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2801,2802 nsp COIL,CHIP DLW21SN900HQ2L D311201219000S
L2804 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L2806 nsp COIL,CHIP DLW21SN181SQ2L D311201211810S
L2807-2810 nsp COIL,BEAD CBW201209U221T D340201202210S
L2812 nsp COIL,BEAD CBW160808U121T D340160811210S
L2813 nsp R,CHIP 0-J, 1/16W C20000006M160S
L2814,2815 nsp R,CHIP 0-J, 1/16W C20000006M160S
L2814,2815 nsp
COIL,CHIP LQM18PN1R5MFR 1.5UH
SMD(1608)-REEL
2113E2 D311160811520S
L3401-3404 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3601-3610 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3613-3622 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3625-3627 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L3628 nsp COIL,BEAD CBW160808U121T D340160811210S
X1301 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X1601 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X2001 943141100020S CRYSTAL CHIP FCX-04(21.875MHz) E80521R875080S
X2201 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S
X2601 141810049509S CRYSTAL CHIP FCX-04(24MHz) E80524R000080S
X3001 00D3991038900 CRYSTAL CHIP FCX-03(12MHz) E805120000020S
K2201 963643003580S TER,RCA 1PIN G600107C0020YS
K3001 ,
K3002
00D9630244703 JACK,D3.5 EARPHONE 2113CIE3 G40130802000YS
N1001 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1002 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1003 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1004 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1201 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1202 nsp CN.FPC 23P L130100162330S
N1301 nsp CN.FPC 23P L130100162330S
N1302 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1601 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N1602 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N2001 nsp CN. FPC 1.0MM 1.0-16-10PB-2 10P L130100161030S
N2201 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N2601 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N2602 nsp CN.FPC 6P 1.0-16-6PB-2 L130100160630S
N2801 nsp CN.WAFER 5P 20010-05 L101200100510S
N2802 963643100130S JACK,MODULAR RJ45 G4060RJ450120S
N3001 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N3002 nsp CN.FPC 11P L130100161130S
N3201 nsp CN.FPC 4P 1.0-9-4PW
2113CIE3, 2113E2,
2113E1C
L130100090450S
N3401 nsp CN,WAFER C125Z2-13 13P L109012521320S
N3402 nsp CN,WAFER C125Z2-09 9P L109012520920S
N3403 nsp CN.WAFER C125Z2-31 31P L109012523120S
N3404 nsp CN,WAFER C125Z2-07 7P L109012520720S

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
