Denon AVR-1913 Service Manual

79
Input
COMPONENT
C
Check on set value of each IC.
Is they the following voltage
values?
HDMI B'D
N3402-4pin : H(5V)
N3402-5pin : L(0V)
N3402-9pin : H(5V)
Is the power supply voltage
correctly output?
V+5V : C5011 : + side
V-5V : C5022 : - side
Is the signal output from the
video amplier?
COMP-Y : R5015
COMP-CB : R5019
COMP-CR : R5023
Check power supply voltage of
IC5002, and surrounding circuitry
soldering.
Check FRONT CONNECTOR
B'D aw, and connection of
FRONT CONNECTOR B'D or
HDMI B'D and VIDEO B'D.
Is the signal input to video amplier?
COMP-Y : C5017 : + side
COMP-CB : C5023 : + side
COMP-CR : C5018 : + side
Check cable between main unit and
player or check player.
Extend HDMI B'D using a jig.
REGULATOR B'D aw.
HDMI B'D aw.
Check connection of FRONT
CONNECTOR BD and AV BD.
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
b
Unless specied, VIDEO B'D part.
Is the power supply voltage
correctly output?
FRONT CONNECTOR B'D
V+5V : CN5001-9pin
V-5V : CN5001-13pin
q
e
w
r
t

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
