Denon AVR-2308CI Service Manual

130
AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308AVC-2308 JP model
PARTS LIST OF P.W.B. UNIT (AVC-2308 JP model)
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
1U-3852D DIGITAL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 nsp LC89057W-VF4A
IC102 nsp EPM3032ATC44-10N
IC103 nsp ADAU1328BSTZ1136
IC104 nsp AZ1117H-3.3TRE1
IC105,106 nsp NJM2115M-TE1 +C
IC107-110 nsp AZ4580MTR-E1
IC111 nsp PQ050DNA1ZPH
IC112 nsp TC74VHC244FT
IC113,114 nsp AZ4580MTR-E1
IC201 nsp UPC2925BT1D-E1-AT
IC202 nsp PQ012GN01ZPH
IC203 nsp W9864G2GH-7
IC204 nsp ADSP21367KSZ1A1136
IC205 nsp DSP ROM SUB ASSY ES29LV160EB-70TGI-M
IC551 nsp BR24L02FV-W
IC552,553 nsp SN74CBT3306PWG4
IC554 nsp SII9135CTU
IC555 nsp UPC2918BT1D-E1-AT
IC556 nsp BR24L02FV-W
IC557,558 nsp SN74CBT3306PWG4
IC601 nsp EPM570F256C5N
IC701 nsp AZ1117H-1.8TRE1
IC702 nsp SII9134CTU
IC801 nsp AZ1117H-3.3TRE1
IC802 nsp AZ1117H-1.8TRE1
IC803 nsp ADV7401BSTZ-110
IC804 nsp AZ1117H-1.8TRE1
IC805 nsp ADV7172KSTZ
IC901 nsp UPC2918BT1D-E1-AT
IC902 nsp FLI2310-LF-CF
IC903 nsp K4S643232H-UC60
IC951 nsp SUB CPU SUB ASSY M3062LFGPGP
IC954 nsp TC74VHC08FT
IC955 nsp AZ1117H-3.3TRE1
IC956,957 nsp TC74VHCT08AFT
TR101,102 nsp KRC102S-RTK/P (10K-10K)
TR103 nsp KRA102S-RTK/P (10K-10K)
TR104,105 nsp 2SK771-5-TB
TR106 nsp KRA104S-RTK/P (47K-47K)
TR107 nsp KRC104S-RTK/P (47K-47K)
TR203 nsp KRC102S-RTK/P (10K-10K)
TR204,205 nsp KRA102S-RTK/P (10K-10K)
TR206 nsp KRC102S-RTK/P (10K-10K)
TR503 nsp KRC102S-RTK/P (10K-10K)
TR506 nsp KRC104S-RTK/P (47K-47K)
TR551 nsp KRC102S-RTK/P (10K-10K)
TR552-555 nsp KRC104S-RTK/P (47K-47K)
TR556 nsp HN1K02FU-TE85L
TR557,558 nsp KRC104S-RTK/P (47K-47K)
TR703 nsp KRC104S-RTK/P (47K-47K)
TR801,802 nsp KRC104S-RTK/P (47K-47K)
TR803-807 nsp 2SA1022-B +C
TR901 nsp KRC104S-RTK/P (47K-47K)
TR951 nsp KTC3875S-GR-RTK/P
TR952 nsp KRC104S-RTK/P (47K-47K)
TR953 nsp 2SC2412KT96(S) +C
TR954 nsp 2SC3326(A/B) +C
