Denon AVR-2308CI Service Manual

152
AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement
parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
2308CIE3 : U.S.A. & Canada model 888E3 : U.S.A. & Canada model
2308BKE2 : Europe model(Black) 2308SRE2 : Europe model(Silver)
2308E2A : Asia model(Premium Silver) 2308JP : Japan model(Premium Silver)
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D 1U- 3852 DIGITAL UNIT ASSY 1U-3852 :2308CIE3,888E3 1 *
1 00D 1U- 3852 A DIGITAL UNIT ASSY
1U-3852A
:2308BKE2,2308SRE2,2308E2A
1*
1 00D 1U- 3852 D DIGITAL UNIT ASSY 1U-3852D :2308JP 1 *
2 nsp A.AUDIO/VIDEO UNIT ASSY 1U-3853 :2308CIE3,888E3 *
2 nsp A.AUDIO/VIDEO UNIT ASSY
1U-3853A
:2308BKE2,2308SRE2,2308E2A
*
2 nsp A.AUDIO/VIDEO UNIT ASSY 1U-3853D :2308JP *
2-1 A.VIDEO UNIT 1
2-2 AUDIO UNIT 1
2-3 PHONO UNIT 1
3 nsp FRONT UNIT ASSY
1U-3855
:2308CIE3,888E3,2308BKE2,
2308SRE2,2308E2A
*
3 nsp FRONT UNIT ASSY 1U-3855D :2308JP *
3-1 FLD UNIT 1
3-2 FUNC UNIT 1
3-3 FRONT IN UNIT 1
3-4 REMOTE/IPOD UNIT 1
3-5 DIGITAL I/O UNIT 1
3-6 V/D JOINT UNIT 1
3-7 UCON CONNECT UNIT 1
3-8 P.SW UNIT 1
3-10 FFC LOCK UNIT 1
4 nsp POWER REG. UNIT ASSY 1U-3841 :2308CIE3,888E3 *
4 nsp POWER REG. UNIT ASSY
1U-3841G
:2308BKE2,2308SRE2,2308E2A
*
4 nsp POWER REG. UNIT ASSY 1U-3841H :2308JP *
4-1 REG UNIT 1
4-6 PRE AMP UNIT 1
4-7 AUDIO CONNECT UNIT 1
4-8 AUDIO LIMIT UNIT 1
4-9 LIMIT CONNECT UNIT 1
4-10 V-POWER JUNCTION UNIT 1
5 nsp POWER AMP UNIT ASSY 1U-3854 :2308CIE3,888E3 *
5 nsp POWER AMP UNIT ASSY
1U-3854G
:2308BKE2,2308SRE2,2308E2A
*
5 nsp POWER AMP UNIT ASSY 1U-3854H :2308JP *
5-1 P.AMP UNIT 1
5-10 REG CONNECT UNIT 1
5-11 P.AMP HOLDER UNIT 1
