Denon AVR-2308CI Service Manual

153
AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308
6 nsp MAIN CPU UNIT ASSY 1U-3857 :2308CIE3,888E3 *
6 nsp MAIN CPU UNIT ASSY
1U-3857G
:2308BKE2,2308SRE2,2308E2A
*
6 nsp MAIN CPU UNIT ASSY 1U-3857H :2308JP *
6-1 MAIN CPU UNIT 1
6-2 POWER UNIT 1
6-3 PRIM/CPU SUPPLY UNIT 1
6-4 UCON JUNCTION UNIT 1
7 nsp FRONT UNIT ASSY 1U-3843 : 888E3 *
7-1 FLD UNIT 1
7-2 FUNC UNIT 1
7-3 H/P UNIT 1
7-4 S.IN UNIT 1
7-5 AUX IN UNIT 1
7-6 OPT IN UNIT 1
7-7 MIC UNIT 1
7-8 JUNCTION UNIT 1
7-9 REMOTE/IPOD UNIT 1
7-10 DIGITAL I/O UNIT 1
7-11 V/D JOINT UNIT 1
7-12 UCON CONNECT UNIT 1
7-13 P.SW UNIT 1
7-14 FFC LOCK UNIT 1
8 nsp D-TERMINAL UNIT 1U-3875A :2308JP 1 *
11 00D 144 3032 003 FRONT PANEL 2308CIE3 1 *
11 00D 144 3033 002 FRONT PANEL 888E3 1 *
11 00D 144 3032 032 FRONT PANEL 2308BKE2 1 *
11 00D 144 3032 016 FRONT PANEL 2308SRE2 1 *
11 00D 144 3032 029 FRONT PANEL 2308E2A 1 *
11 00D 144 3032 045 FRONT PANEL 2308JP 1 *
12 nsp DENON BADGE 2308CIE3,888E3,2308BKE2 1
12 nsp DENON BADGE 2308SRE2 1
12 nsp DENON BADGE 2308E2A,2308JP 1
17 00D 146 2356 207 RCA COVER 2308CIE3,888E3,2308BKE2 1 *
17 00D 146 2356 210 RCA COVER 2308SRE2 1 *
17 00D 146 2356 236 RCA COVER 2308E2A,2308JP 1 *
18 00D 112 1009 002 KNOB(S) ASSY 2308CIE3,2308BKE2 1
18 00D 112 1009 015 KNOB(S) ASSY 2308SRE2 1 *
18 00D 112 1009 028 KNOB(S) ASSY 2308E2A,2308JP 1 *
18 00D 112 1019 005 KNOB(S) ASSY 888E3 1 *
19 00D 112 1005 006 KNOB(M) ASSY 2308CIE3,2308BKE2 1
19 00D 112 1005 019 KNOB(M) ASSY 2308SRE2 1
19 00D 112 1005 022 KNOB(M) ASSY 2308E2A,2308JP 1
19 00D 112 1013 001 KNOB(M) ASSY 888E3 1 *
20 00D 112 1007 004 KNOB(F) ASSY 2308CIE3,2308BKE2 1
20 00D 112 1007 017 KNOB(F) ASSY 2308SRE2 1
20 00D 112 1007 020 KNOB(F) ASSY 2308E2A,2308JP 1
20 00D 112 1016 008 KNOB(F) ASSY 888E3 1 *
21 00D 146 2511 136 INNER PANEL 2308CIE3,2308BKE2 1
21 00D 146 2511 110 INNER PANEL 2308SRE2 1 *
21 00D 146 2511 123 INNER PANEL 2308E2A 1 *
21 00D 146 2511 149 INNER PANEL 2308JP 1 *
21 00D 146 2516 021 INNER PANEL 888E3 1 *
Ref. No. Part No. Part Name Remarks Q'ty New
