Denon AVR-2308CI Service Manual

32
AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308
※ Unless specified, 1U-3853-1 A.VIDEO UNIT part.
P
Input
CVBS
1U-3853-1 A.VIDEO UNIT
Check ± 5VA.
+5VA : CX077-3,4pin
-5VA : CX077-5pin
NG
To troubleshooting 1.1 Power not turn
on.
OK
Check input/output of analog SW.
Input : IC109-13pin
Output : IC109-3pin
NG
Check analog SW settings.
IC109-9,10,11pin : L(0V)
IC109-6pin : L(0V)
NG
Check IC301 and CX073
soldering, or DIGITAL UNIT flaw.
OK
OK
Check soldering of IC109.
Check input/output of AMP.
Input : IC115-5pin
Output : IC115-7pin
NG
Check soldering of IC115 and
surrounding parts.
OK
Check output to 1U-3852 DIGITAL UNIT.
Output V : CX113-5pin
NG
Check soldering of CX113.
OK
To troubleshooting 3.HDMI/DVI.
※ 特に記載がない場合は 1U-3853-1A.VIDEOUNITの部品です。
P
入力
CVBS
1U-3853-1A.VIDEOUNIT
± 5VAの確認
+5VA:CX077-3,4pin
-5VA:CX077-5pin
NG
1.1 電源が入らないのﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
OK
ｱﾅﾛｸﾞ SW の入出力確認
入力:IC109-13pin
出力:IC109-3pin
NG
ｱﾅﾛｸﾞ SW の設定確認
IC109-9,10,11pin:Ｌ(0V)
IC109-6pin:Ｌ(0V)
NG
IC301,CX073 のﾊﾝﾀﾞ付け確認
もしくは DIGITALUNIT の不具合
OK
OK
IC109 のﾊﾝﾀﾞ付け確認
AMP の入出力確認
入力:IC115-5pin
出力:IC115-7pin
NG
IC115及び 周 辺部 品 の
ﾊﾝﾀﾞ付け確認
OK
1U-3852DIGITALUNIT への出力確認
出力 V:CX113-5pin
NG
CX113 のﾊﾝﾀﾞ付け確認
OK
3.HDMI/DVI のﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
