AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308
78 P12/D10 - O C - - Ed I I Notused
79 P11/D9 - O C - - - - I I Notused
80 P10/D8 VOLMUTE O C - - - Z I O/L VOLUMEMUTEcontrolpin
81 P07/D7 MUTEPOWER O C - - - Z O/L O/L ForMUTE+Bcontrolpin
82 P06/D6 SYNCDET I - Lv - Ed Z O/L O/L Sync.detectinputforMAIN(H:Ext.synchronized)
83 P05/D5 OSDMUTE O C - - - Z O/L O/L OSDcontrolpin
84 P04/D4 - O C - - - Z O/L O/L Notused
85 P03/D3 OSDRST O C - - - Z O/L O/L OSDcontrolpin
86 P02/D2 OSDSTR O C - - - Z O/L O/L OSDcontrolpin
87 P01/D1 OSDCLK O C - - - Z O/L O/L OSDcontrolpin
88 P00/D0 OSDDATA O C - - - Z O/L O/L OSDcontrolpin
89 P107/AN7 XMOLINKACTIVE I - - - Ed Z O/L O/L XMRADIOcontrolpin
90 P106/AN6 XMOANTREV I - E ↓ &L - Ed Z O/L O/L XMRADIOcontrolpin
91 P105/AN5 XMIRESET O C - - - Z O/L O/L XMRADIORESETcontrolpin
92 P104/AN4 ACKSUB O C - - Ed Z O/L O/L MAIN-SUBμcomcomm.controlpin
93 P103/AN3 KEY1 I - Lv - Eu Z O/L O/L KEY1SIGNALINPUT
94 P102/AN2 KEY2 I - Lv - Eu Z O/L O/L KEY2SIGNALINPUT
95 P101/AN1 KEY3 I - Lv - Eu Z O/L O/L KEY3SIGNALINPUT
96 AVSS AVSS - - - - - - - - GND
97 P100/AN0 SETOPTION I - Lv - - Z O/L O/L SETOPTIONSELECT
98 VREF VREF - - - - - - - - VREF
99 AVCC AVCC - - - - - - - - POWER5V
100 P97/SIN4 - O - - - Ed Z O/L O/L Notused
Pin PinName Symbol I/O Type Det
Op
(Int.)
Op
(Ext.)
Res Stby Stop Function
Note: Pin No. : Terminal number of microcomputer.
Port Name : The name entered in the data sheet of microcomputer.
Symbol : Symbolized interface function.
I/O : Input or out of part.
“I” = Input port
“O” = Output port
Type : Composition of port in case of output port.
“C” = CMOS output
“N” = NMOS open drain output
“P” = PMOS open drain output
Op : Pull up/Pull down selection information.
“Iu” = Inner microcomputer pull up
“Id” = Inner microcomputer pull down
“Eu” = External microcomputer pull up
“Ed” = External microcomputer pull down
Det : Indicates judging state of input port. Level detection is “LV”; Edge detection is “Ed”; Detection by both shifting is “E&L”;
Serial data detection is “S” (Serial data output is also “S”).
Res : State at reset.
“H” = Outputs High Level at reset
“L” = Outputs Low Level at reset
“Z” = Becomes High impedance mode at reset
STBY : State of port when STANDBY mode.
“O/L” = Output port and “L”
“I” = Input port
Stop : State of port when Stop mode.
“O/L” = Output port and “L”
“I” = Input port
