85
Input
CVBS,COMPONENT
A
Check on set value of each IC.
VSDA : N3402 4PIN
VSCL : N3402 2PIN
Refer to 86 page.
(HDMI B'D)
Is the signal input to video
decoder (U1302)?
<Input signal>
V : R1309
COMPONENT(Y) : R1306
COMPONENT(Cb) : R1308
COMPONENT(Cr) : R1307
(HDMI B'D)
FRONT CONNECTOR B'D aw
or defective connection of the
connector.
The parts between
CONNETOR(N3401) and U1302
are defective
VIDEO B'D aw.
V/COMPONENT : B-
q
REGULATOR B'D aw.
VIDEO B'D and REGULATOR
B'D and connection of the wire
are defective.
HDMI B'D aw.
NO
NO
YES
YES
Is the power supply voltage
correctly output?
V+5V : CP4800-4pin
V-5V : CP4800-1pin
(VIDEO B'D)
NO
YES
• Monitor Out (V/COMPONENT)
VIDEO B'D aw.
V/COMPONENT : B-
w
• HDMI Out
To Troubleshooting "
3.HDMI/
DVI
" (Refer to 89 page.)

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
