Denon AVR-2802 Service Manual

AVR-2802/982
47
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R407 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
For E2
CAPACITORS GROUP
C102 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C103 254 4193 905 Electrolytic 10 uF/16V
CE04W1C100MT (SRA)
C104 254 4196 944 Electrolytic 1 uF/50V CE04W1H010MT (SRA)
C107 256 1058 971 Metalized 0.1 uF/50V CF93A1H104JT (JL)
C109 254 4196 999 Electrolytic 22 uF/50V
CE04W1H220MT (SRA)
C110-113 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C115 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C117 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C120 257 0504 937 Ceramic chip 30 pF/50V CC73CH1H300JT
C121 254 4193 905 Electrolytic 10 uF/16V
CE04W1C100MT (SRA)
C122 257 0511 917 Ceramic chip 0.022 uF/50V CK73F1H223ZT
C125 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C127 254 4525 926 Electrolytic 100 uF/50V
CE04W1H101MT SMG/RE3
C301 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C304 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For E1,E1H,E1C,EUT
C309 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For EU,982,EC,E2
C313 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
C318 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For E1,E1H,E1C,EUT
C324 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For EU,982,EC,E2
C339 254 4536 957 Electrolytic 470 uF/10V
CE04W1A471MT SMG/RE3
C340 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C341 254 4538 939 Electrolytic 47 uF/16V
CE04W1C470MT SMG/RE3
C342 257 0511 920 Ceramic chip 0.047 uF/50V CK73F1H473ZT
C348 254 4538 939 Electrolytic 47 uF/16V
CE04W1C470MT SMG/RE3
C349 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C350 256 1058 984 Metalized 0.12 uF/50V CF93A1H124JT (JL)
C352 254 4522 903 Electrolytic 4.7 uF/35V
CE04W1V4R7MT SMG/RE3
C353 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C354 254 4213 937 Electrolytic 100 uF/6.3V
CE04W0J101MT (SRA)
C355 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C357 254 4534 713 Electrolytic 3300 uF/6.3V
CE04W0J332MC SMG/RE3
For EU,982,EC
259 0007 702 Back up cap. 8200 uF/5.5V SB CAP==822=C
For E2,E1,E1H,E1C,EUT
C358 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C359 254 4533 934 Electrolytic 220 uF/6.3V
CE04W0J221MT SMG/RE3
C376 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C377 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
C378 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
For EU,982,EC,E2
C380 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
C390 256 1058 971 Metalized 0.1 uF/50V CF93A1H104JT (JL)
C392 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
For EU,982,EC,E2
C398 257 0506 951 Ceramic chip 100 pF/50V CC73CH1H101JT
C400 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
C401 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C405 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
C411,412 257 0504 924 Ceramic chip 27 pF/50V CC73CH1H270JT
For E2
C416 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For EU,982,EC,
E1,E1H,E1C,EUT
257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
For E2
C417,418 254 4524 943 Electrolytic 1 uF/50V CE04W1H010MT SMG/RE3
For E2
C419 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
For E2
C420 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
For EU,982,EC
257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
For E2
C421 257 0508 933 Ceramic chip 560 pF/50V CC73CH1H561JT
For E2
C423,424 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C492 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C493 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2
C983 257 0516 909 Ceramic chip 0.022 uF/25V CK73B1E223KT
OTHER PARTS GROUP Q'ty
CW077 205 1000 015 7P FJ connector plug 1
CW142,143 205 1165 002 14P connector plug (TMC-D) 2
CX061 205 0943 018 6P connector base (TUC-P) 1
CX072 205 0943 021 7P connector base (TUC-P) 1
CX081,082 205 0884 096 8P connector base (TUC-P) 2
CX086 205 0884 096 8P connector base (TUC-P) 1
CX093,094 205 0884 038 9P connector base (TUC-P) 2
CX103 205 0884 054 10P connector base (TUC-P) 1
CX111 205 0884 067 11P connector base (TUC-P) 1
CX114 205 1091 024 11P connector base (TWG-P) 1
CX119 205 0884 067 11P connector base (TUC-P) 1
CX121,122 205 0884 070 12P connector base (TUC-P) 2
CX124 205 0884 070 12P connector base (TUC-P) 1
CX131 205 1091 037 13P connector base (TWG-P) 1
CX142,143 205 1164 003 14P connector socket (TMC-D) 2
CX151 205 0884 041 15P connector base (TUC-P) 1
CX152,153 205 0884 041 15P connector base (TUC-P) 2
CX192 205 1091 008 19P connector base (TWG-P) 1
CX932 205 1121 033 3P connector base-L (5268) 1

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
