AVR-2802/982

Ref. No. Part No. Part Name Remarks

Q'ty

Ref. No. Part No. Part Name Remarks

FB304,305 235 0049 900 Beads inductor 2

FL101 393 8033 007 FLD (CM1690C) 1

L101 235 0070 995 Inductor 220uH 1

L102 235 0070 953 Inductor 68uH 1

L308 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT 1

L313-315 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT 3

L319 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT 1

S101-112 212 5611 903 Tact switch 12

S113 212 0373 000 Rotary encoder EC16B 1

S114 212 0422 003 Rotary encoder 1

S115 212 5611 903 Tact switch 1

W724 203 0526 002 1P contact ass'y 1

XL302 399 0532 902 Ceramic 12.5 MHz

CST12.5MTW-TF01

XL401 399 0178 007 Crystal 4.332 MHz For E2 1

1U-3371 REGULATOR UNIT ASS'Y

SEMICONDUCTORS GROUP

IC901,902 263 1100 005 IC KIA7805API

IC905 263 1100 021 IC KIA7812API

IC906 263 1099 022 IC KIA7912PI

IC907 263 1100 005 IC KIA7805API

IC909 263 1099 006 IC KIA7905PI

TR501-504 273 0460 905 Transistor KTC2875B

TR511-514 273 0460 905 Transistor KTC2875B

TR521-524 273 0460 905 Transistor KTC2875B

TR531-534 273 0460 905 Transistor KTC2875B

TR541-544 273 0460 905 Transistor KTC2875B

TR581,582 273 0429 904 Transistor 2SC3311A

TR584 269 0020 906

Transistor DTC114ES(10K-10K)

TR585,586 273 0429 904 Transistor 2SC3311A

TR901 273 0429 904 Transistor 2SC3311A

TR904 272 0158 007 Transistor 2SB/KTB778(R/O)

TR918 272 0158 007 Transistor 2SB/KTB778(R/O)

D903,904 276 0432 903 Diode 1SS270A

D913-915 276 0305 001 Diode S4VB20

D918,919 276 0432 903 Diode 1SS270A

PT901 279 0034 054

Posistor PTH9M04BC222TS2F333

RESISTORS GROUP

R501-504 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For EU,982,EC

247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

For E2,E1,E1H,E1C,EUT

R505,506 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT

For E2,E1,E1H,E1C,EUT

R507,508 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R509,510 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R511 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For EU,982,EC

247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

For E2,E1,E1H,E1C,EUT

R512 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R513 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For EU,982,EC

247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

For E2,E1,E1H,E1C,EUT

R514 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R515 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT

For E2,E1,E1H,E1C,EUT

R516 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

R517,518 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
