AVR-2802/982

Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks

R519,520 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R521-524 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For EU,982,EC

247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

For E2,E1,E1H,E1C,EUT

R525,526 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT

For E2,E1,E1H,E1C,EUT

R527,528 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R529,530 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R531-534 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For EU,982,EC

247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

For E2,E1,E1H,E1C,EUT

R535,536 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT

For E2,E1,E1H,E1C,EUT

R537,538 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R539,540 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R541-544 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R545,546 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

R547,548 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R549,550 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R551,552 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2009 909 Carbon chip 4.7 kohm 1/16W

RM73B--472JT (1608)

For E2,E1,E1H,E1C,EUT

R553,554 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT

R555 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2009 909 Carbon chip 4.7 kohm 1/16W

RM73B--472JT (1608)

For E2,E1,E1H,E1C,EUT

R556 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

R557,558 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT

R559,560 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2009 909 Carbon chip 4.7 kohm 1/16W

RM73B--472JT (1608)

For E2,E1,E1H,E1C,EUT

R561,562 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT

R563,564 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

For EU,982,EC

247 2009 909 Carbon chip 4.7 kohm 1/16W

RM73B--472JT (1608)

For E2,E1,E1H,E1C,EUT

R565,566 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT

R567,568 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

R569,570 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT

R586-594 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

R910 241 2376 919 Carbon film 30 ohm 1/4W(NB) RD14B2E300JNBST

R949 241 2376 919 Carbon film 30 ohm 1/4W(NB) RD14B2E300JNBST

CAPACITORS GROUP

C501-504 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

For EU,982,EC

254 4538 942 Electrolytic 100 uF/16V

CE04W1C101MT SMG/RE3

For E2,E1,E1H,E1C,EUT

C507 254 4524 943 Electrolytic 1 uF/50V

CE04W1H010MT SMG/RE3

C511 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

For EU,982,EC

254 4538 942 Electrolytic 100 uF/16V

CE04W1C101MT SMG/RE3

For E2,E1,E1H,E1C,EUT

C512 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

C513 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

For EU,982,EC

254 4538 942 Electrolytic 100 uF/16V

CE04W1C101MT SMG/RE3

For E2,E1,E1H,E1C,EUT

C514 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

C521-524 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

For EU,982,EC

254 4538 942 Electrolytic 100 uF/16V

CE04W1C101MT SMG/RE3

For E2,E1,E1H,E1C,EUT

C527 254 4524 943 Electrolytic 1 uF/50V

CE04W1H010MT SMG/RE3

C531-534 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

For EU,982,EC

254 4538 942 Electrolytic 100 uF/16V

CE04W1C101MT SMG/RE3

For E2,E1,E1H,E1C,EUT

C541-544 254 4538 913 Electrolytic 22 uF/16V

CE04W1C220MT SMG/RE3

C591,592 254 4524 943 Electrolytic 1 uF/50V

CE04W1H010MT SMG/RE3

C901 253 1181 904 Ceramic 0.01 uF/50V

CK45F1H103ZT(DD-3)

C902 254 4541 939 Electrolytic 47 uF/25V

CE04W1E470MT SMG/RE3

C903 254 4538 939 Electrolytic 47 uF/16V

CE04W1C470MT SMG/RE3

C904 253 9039 906 Ceramic 0.1 uF/25V

CK45=1E104ZT(DD-3)

C906 253 1181 904 Ceramic 0.01 uF/50V

CK45F1H103ZT(DD-3)

C908 254 4538 939 Electrolytic 47 uF/16V

CE04W1C470MT SMG/RE3

C910 253 1181 904 Ceramic 0.01 uF/50V

CK45F1H103ZT(DD-3)

C911 254 4538 939 Electrolytic 47 uF/16V

CE04W1C470MT SMG/RE3

C916,917 254 4541 939 Electrolytic 47 uF/25V

CE04W1E470MT SMG/RE3

C927 254 4472 707 Electrolytic 4700 uF/16V

CE04W1C472MC (SMG)

C930 253 1181 904 Ceramic 0.01 uF/50V

CK45F1H103ZT(DD-3)

C931 254 4406 702 Electrolytic 3300 uF/16V

CE04W1C332MC(SMG)

C934 254 4403 734 Electrolytic 4700 uF/25V

CE04W1E472MC(SMG)

C935 254 4403 718 Electrolytic 1000 uF/25V

CE04W1E102MC (SMG)

C936-939 256 1058 971 Metalized 0.1 uF/50V CF93A1H104JT (JL)

C940,941 256 1058 971 Metalized 0.1 uF/50V CF93A1H104JT (JL)

C942 254 4538 939 Electrolytic 47 uF/16V

CE04W1C470MT SMG/RE3

C948 254 4539 718 Electrolytic 2200 uF/16V

CE04W1C222MC SMG/RE3

C952 254 4524 943 Electrolytic 1 uF/50V

CE04W1H010MT SMG/RE3

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
