Denon AVR-2802 Service Manual

AVR-2802/982
50
Ref. No. Part No. Part Name Remarks Q’ty Ref. No. Part No. Part Name Remarks
1U-3373 DSP/VIDEO UNIT ASS'Y
OTHER PARTS GROUP
CW045 205 0885 082 4P connector socket (TUC-P) 1
CW054-058 205 0885 008 5P connector socket (TUC-P) 5
CW076 205 0942 022 7P connector socket (TUC-P) 1
CW096 205 0885 037 9P connector socket (TUC-P) 1
CW125 205 0885 079 12P connector socket (TUC-P) 1
CW151 205 0885 040 15P connector socket (TUC-P) 1
CW154 205 0885 040 15P connector socket (TUC-P) 1
CX031 205 0321 038
3P connector base (KR-PH RED) 1
CX073 205 0343 074 7P connector base (KR-PH) 1
CX091 205 0233 090 9P EH connector base 1
CX113 205 1091 024 11P connector base (TWG-P) 1
CX116 205 1091 024 11P connector base (TWG-P) 1
CX154 205 0884 041 15P connector base (TUC-P) 1
CX159 205 0770 045 15P FFC base (SIDE) 1
CX191 205 1091 008 19P connector base (TWG-P) 1
CY021 205 0581 001 2P VH connector base For E2,E1,
E1H,E1C,EUT 1
F11-15 206 1039 076 Fuse 2.5A For EU,982,
EC,EUT 5
206 1015 032 Fuse 2.5A For E2,E1,
E1H,E1C 5
FF901-905 202 0040 909 Fuse clip 5
FH901-905 202 0040 909 Fuse clip 5
JK501 204 8543 006 6P pin jack 1
JK502 204 8540 009 4P pin jack 1
S901 212 1030 009 Power switch (TV-5) For E2,E1,
E1H,E1C,EUT 1
ST101  Style pin 1
ST501 205 1034 010 M3 Screw terminal 1
415 0309 026 P.V.C. tube(L=20) For PT901 1
513 2585 074 Fuse label For F11-15
For E2,E1,E1H,E1C 5
SEMICONDUCTORS GROUP
IC107 262 2545 006 IC TC9274N-011
IC108 262 2033 000 IC TC9273N-004
IC109 263 0896 909 IC NJM2068MD
IC112 263 0615 902 IC BA15218F
IC251,252 262 2826 903 IC BU4051BCF
IC253,254 263 1082 903 IC TK15420MTL
IC255 262 2012 908 IC BU4052BCFT1
IC256 262 2013 907 IC BU4053BCFT1
IC257 263 1082 903 IC TK15420MTL
IC301 262 2983 105 IC TMP93CS40F
IC451 262 2827 902 IC MM74HC4053SJ
IC452 263 0682 003 IC NJM2229S
IC453 262 2808 002 IC M35015-210SP
IC501-503 263 1082 903 IC TK15420MTL
IC504-507 262 2826 903 IC BU4051BCF
IC508 263 1082 903 IC TK15420MTL
IC509,510 262 2012 908 IC BU4052BCFT1
IC511 263 1082 903 IC TK15420MTL
IC601 262 2747 901 IC AD1854JRSRL
IC602 262 2950 002 IC AK4527BVQ
IC701 263 0896 909 IC NJM2068MD
IC721 263 0896 909 IC NJM2068MD
IC741 263 0896 909 IC NJM2068MD
IC761 263 0896 909 IC NJM2068MD
IC800 262 2675 015 IC LC89055W
IC801 262 2608 901 IC TC74VHC123AFT
IC804 262 2870 904 IC 74LVX157MTC
IC807 262 2519 906 IC SN74LV00APW-EL2
IC809 262 2557 900 IC SN74LV14APW-EL2
IC811,812 263 0934 900 IC BA4510F
IC813 262 2781 909 IC SN74LV4040APW
IC814 262 2949 903 IC CS493292-CL
IC815,816 262 2660 907 IC SN74AHC574PW
IC817 262 3010 006 IC AT49LV002-70TC
IC818 262 2959 906 IC SN74LV244APW
IC819 263 1048 002 IC BA033T
IC823 262 2376 903 IC TC74HCT7007AF
IC824 263 1129 905 IC NJM2391DL1
IC825 262 2959 906 IC SN74LV244APW
TR305 269 0082 902 Transistor DTC114EK
TR453,454 269 0048 904 Transistor DTC143EK
TR455,456 273 0384 900 Transistor 2SC2412K(S)

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
