AVR-2802/982

Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R163,164 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R173,174 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R175,176 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R177,178 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R179,180 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R181,182 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R183,184 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

R187-190 247 2012 996 Carbon chip 200 kohm 1/16W RM73B--204JT

R191,192 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R195,196 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

R197-200 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R201,202 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT

R203-206 247 2012 996 Carbon chip 200 kohm 1/16W RM73B--204JT

R207-210 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R235,236 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

R251-255 247 2004 975 Carbon chip 75 ohm 1/16W RM73B--750JT

R256-258 247 2010 969 Carbon chip 22 kohm 1/16W RM73B--223JT

R259-261 247 2004 975 Carbon chip 75 ohm 1/16W RM73B--750JT

R263 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R264 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R265 247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

R266 247 2006 986 Carbon chip 560 ohm 1/16W RM73B--561JT

R268 247 2002 964 Carbon chip 10 ohm 1/16W RM73B--100JT

R269-271 247 2008 913 Carbon chip 2 kohm 1/16W RM73B--202JT

R275-277 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R278-280 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R281 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R282,283 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

R284 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R285 247 2008 913 Carbon chip 2 kohm 1/16W RM73B--202JT

R286 247 2006 973 Carbon chip 510 ohm 1/16W RM73B--511JT

R287 247 2006 999 Carbon chip 620 ohm 1/16W RM73B--621JT

R291 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R292 247 2002 964 Carbon chip 10 ohm 1/16W RM73B--100JT

R293 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

R301,302 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R303 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT

R304 247 2009 909 Carbon chip 4.7 kohm 1/16W

RM73B--472JT (1608)

R305,306 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT

R307 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R308 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT

R309 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R311,312 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT

R313 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R314-327 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT

R328 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT

R331 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

R334 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT

TR501 271 0300 904 Transistor KTA1266GR

TR502 269 0020 906

Transistor DTC114ES(10K-10K)

TR503 269 0082 902 Transistor DTC114EK

TR601 269 0083 901 Transistor DTA114EK

TR602 269 0082 902 Transistor DTC114EK

TR603-607 269 0083 901 Transistor DTA114EK

TR701-704 273 0460 905 Transistor KTC2875B

TR721-724 273 0460 905 Transistor KTC2875B

TR741-744 273 0460 905 Transistor KTC2875B

TR761-764 273 0460 905 Transistor KTC2875B

D251,252 276 0559 909 Diode DAP202KT146

D453 276 0560 901 Diode DAN202KT146

D457,458 276 0559 909 Diode DAP202KT146

D459 276 0559 909 Diode DAP202KT146

D501,502 276 0559 909 Diode DAP202KT146

D601 276 0560 901 Diode DAN202KT146

D603 276 0560 901 Diode DAN202KT146

RESISTORS GROUP

R101,102 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R103,104 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R113,114 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R115,116 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R125,126 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R127,128 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R137,138 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R139,140 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R149,150 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT

For E2,E1,E1H,E1C,EUT

R151,152 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT

R161,162 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT

For EU,982,EC

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)

Denon AVR-2802 Service Manual
