Denon AVR-2802 Service Manual

AVR-2802/982
53
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R761,762 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R763-770 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R771,772 247 2007 927 Carbon chip 820 ohm 1/16W RM73B--821JT
R773,774 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R775,776 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R777,778 247 2005 974 Carbon chip 200 ohm 1/16W RM73B--201JT
R780 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R781,782 247 2005 974 Carbon chip 200 ohm 1/16W RM73B--201JT
R783-798 247 2011 900 Carbon chip 33 kohm 1/16W RM73B--333JT
R799 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R800-805 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R806 247 2008 968 Carbon chip 3.3 kohm 1/16W RM73B--332JT
R807,808 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R810,811 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R813 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R815 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R816 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R817 247 2009 967 Carbon chip 8.2 kohm 1/16W RM73B--822JT
R818 247 2008 955 Carbon chip 3 kohm 1/16W RM73B--302JT
R819 247 2009 912 Carbon chip 5.1 kohm 1/16W RM73B--512JT
R820 247 2004 975 Carbon chip 75 ohm 1/16W RM73B--750JT
R822-825 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R826,827 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R828 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R829 247 2011 900 Carbon chip 33 kohm 1/16W RM73B--333JT
R830 247 2014 965 Carbon chip 1 Mohm 1/16W RM73B--105JT
R831 247 2011 900 Carbon chip 33 kohm 1/16W RM73B--333JT
R832 247 2014 965 Carbon chip 1 Mohm 1/16W RM73B--105JT
R833,834 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R835 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R837,838 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R839,840 247 2009 938 Carbon chip 6.2 kohm 1/16W RM73B--622JT
R841,842 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R843,844 247 2010 943 Carbon chip 18 kohm 1/16W RM73B--183JT
R847,848 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R849 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R854 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R856 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R860 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R863 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R869-872 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R873-876 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R877-884 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R896 247 2003 947 Carbon chip 22 ohm 1/16W RM73B--220JT
R897 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R898 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R924 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
R925-948 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R949 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R951 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R955-957 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R961,962 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R963 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R965 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R966 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
CAPACITORS GROUP
C101,102 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C113,114 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C125,126 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C137,138 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C149,150 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C161,162 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
For E2,E1,E1H,E1C,EUT
C167-172 257 0506 951 Ceramic chip 100 pF/50V CC73CH1H101JT
C173,174 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C177 256 1059 954 Metalized 0.47 uF/50V CF93A1H474JT (JL)
C178 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C185,186 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C187 257 0507 934 Ceramic chip 220 pF/50V CC73CH1H221JT
C188 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C189,190 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C193,194 254 4524 943 Electrolytic 1 uF/50V CE04W1H010MT SMG/RE3
C195,196 254 4524 998 Electrolytic 22 uF/50V CE04W1H220MT SMG/RE3
For EU,982,EC,
E1,E1H,E1C,EUT
254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
For E2
C197,198 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
C251-254 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C255 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C257-260 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
C261,262 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C263 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C265 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
C266 254 4536 928 Electrolytic 100 uF/10V CE04W1A101MT SMG/RE3
C267 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
C269-272 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C273 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C277,278 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C301,302 257 0511 920 Ceramic chip 0.047 uF/50V CK73F1H473ZT
C306 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C307 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C311 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C312 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
