Denon AVR-2802 Service Manual

AVR-2802/982
54
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C313 254 4524 943 Electrolytic 1 uF/50V CE04W1H010MT SMG/RE3
C451 254 4538 900 Electrolytic 10 uF/16V CE04W1C100MT SMG/RE3
C452,453 257 0511 920 Ceramic chip 0.047 uF/50V CK73F1H473ZT
C457 257 0504 940 Ceramic chip 33 pF/50V CC73CH1H330JT
C458 257 0501 901 Ceramic chip 0.01 uF/50V
CK73B1H103KT (1608)
C459,460 257 0503 925 Ceramic chip 10 pF/50V CC73CH1H100DT
C461 255 1265 978 Mylar film 0.022 uF/50V CQ93M1H223JT(B)
C462 254 4524 972 Electrolytic 4.7 uF/50V
CE04W1H4R7MT SMG/RE3
C463 257 0506 951 Ceramic chip 100 pF/50V CC73CH1H101JT
C464 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C465 254 4538 900 Electrolytic 10 uF/16V CE04W1C100MT SMG/RE3
C466 255 1264 908 Mylar film 1000 pF/50V CQ93M1H102JT(B)
C467 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C468 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C469 255 1264 911 Mylar film 1200 pF/50V CQ93M1H122JT(B)
C470 257 0506 993 Ceramic chip 150 pF/50V CC73CH1H151JT
C471 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C472 256 1058 955 Metalized 0.068 uF/50V CF93A1H683JT (JL)
C473 257 0508 917 Ceramic chip 470 pF/50V CC73CH1H471JT
C474 257 0510 918 Ceramic chip 3300 pF/50V CK73B1H332KT
C478 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C479 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C480-483 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C484 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
For E1,E1H
C486,487 257 0504 940 Ceramic chip 33 pF/50V CC73CH1H330JT
C488 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C489 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C490 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
C501-504 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
C505-512 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C513,514 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C517,518 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
C519-524 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C525,526 254 4538 939 Electrolytic 47 uF/16V
CE04W1C470MT SMG/RE3
C529-531 254 4536 928 Electrolytic 100 uF/10V CE04W1A101MT SMG/RE3
C532,533 256 1058 939 Metalized 0.047 uF/50V CF93A1H473JT (JL)
C534 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C535 256 1058 939 Metalized 0.047 uF/50V CF93A1H473JT (JL)
C536-539 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C540 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C541 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C588 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C601 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C602 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C604 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C605,606 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C607 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C608 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C622 257 0506 951 Ceramic chip 100 pF/50V CC73CH1H101JT
C623 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C624 254 4536 928 Electrolytic 100 uF/10V
CE04W1A101MT SMG/RE3
C625 254 4524 956 Electrolytic 2.2 uF/50V CE04W1H2R2MT SMG/RE3
C626 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C627 254 4538 900 Electrolytic 10 uF/16V
CE04W1C100MT SMG/RE3
C628 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C701-704 257 0508 933 Ceramic chip 560 pF/50V CC73CH1H561JT
C705,706 257 0506 919 Ceramic chip 68 pF/50V CC73CH1H680JT
C707,708 257 0507 918 Ceramic chip 180 pF/50V CC73CH1H181JT
C709,710 255 1264 940 Mylar film 2200 pF/50V CQ93M1H222JT(B)
C711,712 254 4524 998 Electrolytic 22 uF/50V CE04W1H220MT SMG/RE3
C721,722 254 4524 985 Electrolytic 10 uF/50V CE04W1H100MT SMG/RE3
C723-726 257 0508 959 Ceramic chip 680 pF/25V CC73CH1E681JT
C727,728 254 4524 998 Electrolytic 22 uF/50V
CE04W1H220MT SMG/RE3
C729,730 255 1264 982 Mylar film 4700 pF/50V CQ93M1H472JT(B)
C741,742 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C743-746 257 0508 959 Ceramic chip 680 pF/25V CC73CH1E681JT
C747,748 254 4524 998 Electrolytic 22 uF/50V
CE04W1H220MT SMG/RE3
C749,750 255 1264 982 Mylar film 4700 pF/50V CQ93M1H472JT(B)
C761,762 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C763-766 257 0508 959 Ceramic chip 680 pF/25V CC73CH1E681JT
C767,768 254 4524 998 Electrolytic 22 uF/50V
CE04W1H220MT SMG/RE3
C769,770 255 1264 982 Mylar film 4700 pF/50V CQ93M1H472JT(B)
C781 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C782,783 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C784 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C787 254 4524 901 Electrolytic 0.1 uF/50V CE04W1H0R1MT SMG/RE3
C789 254 4524 901 Electrolytic 0.1 uF/50V CE04W1H0R1MT SMG/RE3
C800-803 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C804 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C805,806 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C807 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C808 257 0011 996 Ceramic chip 0.1 uF/25V CK73B1E104KT
C809 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C810 257 0501 901 Ceramic chip 0.01 uF/50V
CK73B1H103KT (1608)
C811 254 4524 943 Electrolytic 1 uF/50V CE04W1H010MT SMG/RE3
C812,813 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C814 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C815 254 4524 956 Electrolytic 2.2 uF/50V
CE04W1H2R2MT SMG/RE3
C816 257 0508 917 Ceramic chip 470 pF/50V CC73CH1H471JT
C817 255 1265 936 Mylar film 0.01 uF/50V CQ93M1H103JT(B)
C818 257 0509 929 Ceramic chip 1000 pF/50V CK73B1H102KT
C819 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C820 257 0512 903 Ceramic chip 0.1 uF/25V CK73F1E104ZT
C821 257 0507 976 Ceramic chip 330 pF/50V CC73CH1H331JT
C822,823 257 0504 966 Ceramic chip 39 pF/50V CC73CH1H390JT
C825 257 0511 904 Ceramic chip 0.01 uF/50V CK73F1H103ZT
C833 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C834,835 254 4538 900 Electrolytic 10 uF/16V CE04W1C100MT SMG/RE3

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
