Denon AVR-2809CI

115
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
8U-110031E MAIN CPU P.W.B. UNIT ASS'Y (for EU, EC model)
8U-110031K MAIN CPU P.W.B. UNIT ASS'Y (for 989EU model)
8U-110031G MAIN CPU P.W.B. UNIT ASS'Y (for E2 model)
8U-110031H MAIN CPU P.W.B. UNIT ASS'Y (for E1C model)
8U-110031J MAIN CPU P.W.B. UNIT ASS'Y (for JP model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D2631286903 PQ120DNA1ZPH
IC104 00D2623571901 HIN202EIBNZ-T
IC105 8R2431001300D MAIN CPU SUB ASSY
(M30879FLBFP)
IC106,107 00D2622375904 IC, TC4094BF(TP1) +C
IC109 00D2631289900 AZ4580MTR-E1
IC112 00D2631289900 AZ4580MTR-E1 E1C, JP
IC301 00D2623360905 LC72722PM-TLM E2
IC302 00D2631289900 AZ4580MTR-E1 EU, 989EU, EC, E2
IC502 00D2631035002 PQ30RV11
IC504 00D2631280006 SI-8008HFE
IC505,506 00D2631288901 PQ050DNA1ZPH
TR103 00D2710326904 2SA1954(B)-TE85L
TR104 00D2690192902 KRC102S-RTK/P (10K-10K)
TR105-107 00D2730464901 KTC3875S-GR-RTK/P
TR108 00D2690193901 KRC104S-RTK/P (47K-47K)
TR109 00D2690191903 KRA104S-RTK/P (47K-47K)
TR110 00D2690193901 KRC104S-RTK/P (47K-47K)
TR111 00D2690192902 KRC102S-RTK/P (10K-10K)
TR112 00D2710326904 2SA1954(B)-TE85L
TR115 00D2710326904 2SA1954(B)-TE85L
TR116 00D2690192902 KRC102S-RTK/P (10K-10K)
TR301,302 00D2690192902 KRC102S-RTK/P (10K-10K) E2
TR303 00D2690086908 DTA114TKT96 +C E2
TR304,305 00D2690066902 DTC323TKT96 +C E2
TR501 00D2730464901 KTC3875S-GR-RTK/P
TR505 00D2720158007 KTB778-O-U/P
TR506 00D2730468907 KTC3199-GR-AT/P
TR507,508 00D2730464901 KTC3875S-GR-RTK/P
TR509 00D2690192902 KRC102S-RTK/P (10K-10K)
TR510 00D2710313904 KTA1281-Y-AT/P
TR511 00D2690192902 KRC102S-RTK/P (10K-10K)
TR512,513 00D2730468907 KTC3199-GR-AT/P
TR514 00D2730464901 KTC3875S-GR-RTK/P
D103,104 00D2760794900 KDS160-RTK/P
D106,107 00D2760704903 1SR35-400A(T93X)
D108 00D2760740909 KDS184-RTK/P (K-COM)
D301-303 00D2760704903 1SR35-400A(T93X)
D501-506 00D2760704903 1SR35-400A(T93X)
D508 00D2760704903 1SR35-400A(T93X)
D510 00D2760850705 RSX1001T3
D511 00D2760401905 1SS133T77 (TAPE)
D514,515 00D2760704903 1SR35-400A(T93X)
D517-521 00D2760704903 1SR35-400A(T93X)
D522,523 00D2760855001 D3SB20-7103
D526-528 00D2760401905 1SS133T77 (TAPE)
ZD101 00D2760459915 HZS5B-2TD
ZD501 00D2760463901 HZS6C-1TD EU, 989EU, EC, JP
ZD501 00D2760462915 HZS6B-2TD E2, E1C
ZD505 00D2760637902 MTZJ6.2AT77
ZD506 00D2760477900 HZS16-1 TD(TAPE)
ご注意：
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
