Denon AVR-2809CI

141
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU (AVR-2809 ): U.S.A. model 989EU (AVR-989): U.S.A. model EC (AVR-2809) :Canada model
E2 (AVR-2809) : Europe model E1C (AVC-2809) : China model JP (AVC-2809) : Japan mode
BK : Black model SP : Premium silver model
Ref. No. Part No. Part Name Remarks Q'ty New
1 8U-310003 DIGITAL UNIT EU, EC 1
1 8U-310003A DIGITAL UNIT 989EU 1
1 8U-310003B DIGITAL UNIT E2, E1C 1
1 8U-310003D DIGITAL UNIT JP 1
2 nsp A.AUDIO/VIDEO UNIT EU, EC 1
2 nsp A.AUDIO/VIDEO UNIT 989EU 1
2 nsp A.AUDIO/VIDEO UNIT E2, E1C 1
2 nsp A.AUDIO/VIDEO UNIT JP 1
2-1 A.VIDEO UNIT
2-2 AUDIO UNIT
2-3 ZONE UNIT
2-4 STANDBY POWER UNIT
3 nsp FRONT UNIT EU, 989EU, EC 1
3 nsp FRONT UNIT E2, E1C 1
3 nsp FRONT UNIT JP 1
3-1 FLD UNIT
3-2 FUNC UNIT
3-3 FRONT IN UNIT
3-4 MIC UNIT
3-5 REMOTE/IPOD UNIT
3-6 DIGITAL I/O UNIT
3-7 V/D JOINT UNIT
3-8 UCON CONNECT UNIT
3-9 P.SW UNIT
3-10 D-TERMINAL UNIT JP
3-11 FFC LOCK UNIT
3-12 BKT1 UNIT
3-13 BKT2 UNIT
3-14 BKT3 UNIT
3-17 VOLUNE UNIT
3-18 FUNC CONNECT UNIT
4 nsp POWER REG UNIT EU, EC 1
4 nsp POWER REG UNIT 989EU 1
4 nsp POWER REG UNIT E2, E1C 1
4 nsp POWER REG UNIT JP 1
4-1 REG UNIT
4-6 PRE AMP UNIT
4-7 AUDIO LIMIT UNIT
4-8 AUDIO CONNECT UNIT
4-9 LIMIT CONNECT UNIT
