Denon AVR-2809CI

7
AVR-2809CI/AVR-989/AVR-2809/AVC-2809
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
TOP COVER SUB ASS
Y
FRONT UNIT ASS
Y
DIGITAL UNIT ASS
Y
Refer to "DISASSEMBLY 1.FRONT UNIT ASSY" Refer to "DISASSEMBLY 2.DIGITAL UNIT ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
FLD UNIT DIGITAL UNIT ASSY
(Ref. No. of EXPLODED VIEW : 3-1) (Ref. No. of EXPLODED VIEW : 1)
FUNC UNIT
(Ref. No. of EXPLODED VIEW : 3-2)
BACK PANEL ASS
Y
FRONT IN UNIT Refer to "DISASSEMBLY 3.BACK PANEL ASSY"
(Ref. No. of EXPLODED VIEW : 3-3) and "EXPLODED VIEW"
MIC UNIT DIGITAL I/O UNIT
(Ref. No. of EXPLODED VIEW : 3-4) (Ref. No. of EXPLODED VIEW : 3-6)
P.SW UNIT
(Ref. No. of EXPLODED VIEW : 3-9)
A.VIDEO UNIT ASS
Y
Refer to "DISASSEMBLY 4.A.VIDEO UNIT ASSY"
and "EXPLODED VIEW"
A.VIDEO UNIT
(Ref. No. of EXPLODED VIEW : 2-1)
TRANS AUDIO UNIT ASS
Y
Refer to "DISASSEMBLY 14.TRANS" Refer to "DISASSEMBLY 5.AUDIO UNIT ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
TRANS AUDIO UNIT
(Ref. No. of EXPLODED VIEW : 42) (Ref. No. of EXPLODED VIEW : 2-2)
ZONE UNIT
(Ref. No. of EXPLODED VIEW : 2-3)
UCON CONNECT UNIT
Refer to "DISASSEMBLY 6.UCON CONNECT UNIT"
and "EXPLODED VIEW"
UCON CONNECT UNIT
(Ref. No. of EXPLODED VIEW : 3-8)
AUDIO LIMIT UNIT AM FM TUNE
R
Refer to "DISASSEMBLY 8.AUDIO LIMIT UNIT" REMOTE IPOD UNIT
and "EXPLODED VIEW" Refer to "DISASSEMBLY 7.AM FM TUNER
/
AUDIO LIMIT UNIT REMOTE IPOD UNIT"
(Ref. No. of EXPLODED VIEW : 4-7) and "EXPLODED VIEW"
AM FM TUNER
(Ref. No. of EXPLODED VIEW : 44)
REMOTE IPOD UNIT
(Ref. No. of EXPLODED VIEW : 3-5)
MAIN CPU UNIT ASS
Y
Refer to "DISASSEMBLY 9.MAIN CPU UNIT ASSY
and "EXPLODED VIEW"
MAIN CPU UNIT
(Ref. No. of EXPLODED VIEW : 6-1)
PRIM/CPU SUPPLY UNIT ASS
Y
REG UNIT ASS
Y
Refer to "DISASSEMBLY 13.PRIM/CPU SUPPLY ASSY" Refer to "DISASSEMBLY 10.REG UNIT ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
POWER UNIT REG UNIT
(Ref. No. of EXPLODED VIEW : 6-2) (Ref. No. of EXPLODED VIEW : 4-1)
PRIM/CPU SUPPLY UNIT
(Ref. No. of EXPLODED VIEW : 6-3)
PRE AMP UNIT ASS
Y
UCON JUNCTION UNIT Refer to "DISASSEMBLY 11. PRE AMP UNIT ASSY"
(Ref. No. of EXPLODED VIEW : 6-4) and "EXPLODED VIEW"
PRE AMP UNIT
(Ref. No. of EXPLODED VIEW : 4-6)
POWER AMP UNIT ASS
Y
Refer to "DISASSEMBLY 12.POWER AMP UNIT ASSY
"
and "EXPLODED VIEW"
REG UNIT
(Ref. No. of EXPLODED VIEW : 5-1)
