AVR-2809CI/AVR-989/AVR-2809/AVC-2809
1. FRONT UNIT ASSY
(1) Disconnect the connector wires. ( コネクタワイヤーをはずす。）
Proceeding (手順) : TOP COVER SUB ASSY → FRONT UNIT ASSY
CX062
Top view
cut
CX021
EU model
CX062
Top view
cut
CX021
EC, E2, E1C, JP model
