6
AVR-3310CI/AVR-3310/AVR990/AVC-3310
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling" it.
TOP COVER
DIGITAL UNIT ASSY FRONT PANEL UNIT ASSY
Refer to "DISASSEMBLY
REG UNIT
Refer to "DISASSEMBLY
2. DIGITAL UNIT ASSY" Refer to "DISASSEMBLY 1.FRONT PANEL UNIT ASSY"
and "EXPLODED VIEW" 5. REG UNIT" P.SW UNIT
DIGITAL UNIT and "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : A-8)
(Ref. No. of EXPLODED VIEW : G) REG UNIT FRONT USB UNIT
(Ref. No. of EXPLODED VIEW : B-4) (Ref. No. of EXPLODED VIEW : E-3)
REG CONNECT-1 UNIT MIC UNIT
BACK PANEL UNIT ASSY
(Ref. No. of EXPLODED VIEW : A-15) (Ref. No. of EXPLODED VIEW : A-9)
Refer to "DISASSEMBLY CONNECT UNIT-2 FRONT IN UNIT
3. BACK PANEL UNIT ASSY" (Ref. No. of EXPLODED VIEW : D-4) (Ref. No. of EXPLODED VIEW : A-10)
PTC UNIT VR CONNECT UNIT
(Ref. No. of EXPLODED VIEW : A-5)
A.VIDEO UNIT, A.AUDIO UNIT
VOLUME UNIT
and RADIATOR UNIT ASSY SPEAKER UNIT
(Ref. No. of EXPLODED VIEW : A-4)
Refer to "DISASSEMBLY Refer to "DISASSEMBLY FUNC CONNECT UNIT
4. A.VIDEO UNIT, A.AUDIO UNIT 6. AMP UNIT" (Ref. No. of EXPLODED VIEW : A-7)
and RADIATOR UNIT ASSY" and "EXPLODED VIEW" FUNC UNIT
and "EXPLODED VIEW" SPEAKER UNIT (Ref. No. of EXPLODED VIEW : A-6)
A.VIDEO UNIT (Ref. No. of EXPLODED VIEW : D-1) FLD UNIT
(Ref. No. of EXPLODED VIEW : E-1) (Ref. No. of EXPLODED VIEW : A-1)
A.AUDIO UNIT
(Ref. No. of EXPLODED VIEW : E-2)
AMP CONNECT UNIT
MAIN CPU UNIT Refer to "DISASSEMBLY
(Ref. No. of EXPLODED VIEW : F) 7. AMP CONNECT UNIT"
REMOTE/IPOD UNIT and "EXPLODED VIEW"
(Ref. No. of EXPLODED VIEW : B-5) AMP CONNECT UNIT
232C UNIT (Ref. No. of EXPLODED VIEW : D-2)
(Ref. No. of EXPLODED VIEW : B-6)
P.AMP UNIT
Refer to "DISASSEMBLY
9.P.AMP UNIT"
and "EXPLODED VIEW"
P.AMP UNIT
(Ref. No. of EXPLODED VIEW : C-1〜7)
